📌 Product Overview
The XL-0201UOC is a surface-mount LED from XINGLIGHT, characterized by its ultra-compact 0201 package (0.65x0.35x0.4mm) and high-brightness orange emission. Engineered for miniaturization, it is ideal for applications requiring space-constrained visual indicators. Its design prioritizes compatibility with automated assembly processes, making it a reliable choice for high-volume production in consumer electronics and smart devices.
💡 Typical Applications
- Signal indication for status and alerts
- LCD backlighting for small displays
- Integration into 3C products (computers, communication, consumer electronics)
- Artificial intelligence system status indicators
- IoT device visual feedback
- Smart wearable technology
🔬 Key Technical Specifications
| Parameter | Symbol | Min | Typ | Max | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Luminous Intensity | Iv | 80 | / | 240 | mcd | IF=20mA |
| Dominant Wavelength | λd | 600 | / | 610 | nm | IF=20mA |
| Peak Wavelength | λp | / | 605 | / | nm | IF=20mA |
| Forward Voltage | VF | 1.7 | / | 2.3 | V | IF=20mA |
| Viewing Angle | 2Ø1/2 | / | 120° | / | deg | IF=20mA |
⚠️ Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Value | Unit |
|---|---|---|---|
| Max Power Dissipation | PD | 50 | mW |
| Max Continuous Forward Current | IF | 20 | mA |
| Peak Forward Current | IFP | 80 | mA |
| Max Reverse Voltage | VR | 5 | V |
| Operating Temperature | TOPR | -40 ~ +85 | °C |
| Soldering Temperature | TSOL | 260℃≤6s | / |
📏 Package, Dimensions & Assembly Notes
The XL-0201UOC utilizes a standard 0201 surface-mount package with dimensions of 0.65x0.35x0.4mm. It is compatible with automatic pick-and-place mounters and designed for reflow soldering processes. The component has a Moisture Sensitivity Level (MSL) of 3 and complies with EIA standard packaging, ensuring reliability in automated assembly environments.
🚀 Sourcing & Supply Considerations
- RoHS-compliant for environmental compliance.
- Available in brightness (D2-D6) and voltage (N11-3 to N11-5) grades for specific application needs.
- Authenticity verification recommended through authorized XINGLIGHT channels to avoid counterfeit components.
❓ FAQ
Q: What is the peak wavelength of the XL-0201UOC?
A: The typical peak wavelength (λp) is 605 nm, measured at IF=20mA.
Q: Is this LED suitable for lead-free soldering processes?
A: Yes, it is suitable for both leaded and lead-free reflow soldering, with a maximum soldering temperature of 260°C for ≤6 seconds.
Q: Can the XL-0201UOC be used in high-temperature environments?
A: Yes, its operating temperature range is -40°C to +85°C, making it suitable for demanding environments.
Q: What are the available brightness grades?
A: Brightness is graded from D2 (80-120 mcd) to D6 (210-240 mcd) at IF=20mA.
Q: Does this LED require special handling due to moisture sensitivity?
A: Yes, it has an MSL of 3, requiring standard moisture-sensitive handling procedures during storage and assembly.
