📌 Product Overview
The XL-1005SURC-F is a miniature 0402 surface-mount LED (SMD) emitting bright red light, designed for compact electronic applications. With ultra-small dimensions (1.0x0.5x0.4mm) and RoHS compliance, it supports high-density PCB layouts. Ideal for precision backlighting and status indicators in space-constrained devices, its focus is on reliability and SMT compatibility.
🔍 Typical Applications
- Automotive: Backlight keypads, dashboard indicators
- Industrial: Control panels, equipment status lights
- Consumer Electronics: Mobile phone buttons, router indicators
- General: LED backlights, power-status displays
📊 Key Technical Specifications
| Parameter | Symbol | Min | Typ | Max | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Luminous Intensity | Iv | 80 | - | 240 | mcd | IF=20mA |
| Dominant Wavelength | λd | 620 | - | 630 | nm | IF=20mA |
| Forward Voltage | VF | 1.8 | - | 2.1 | V | IF=20mA |
| Viewing Angle | 2Ø1/2 | - | 120° | - | deg | IF=20mA |
⚠️ Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Value | Unit |
|---|---|---|---|
| Max Power Dissipation | PD | 50 | mW |
| Max Continuous Forward Current | IF | 20 | mA |
| Peak Forward Current | IFP | 60 | mA |
| Operating Temperature | TOPR | -40 ~ +85 | °C |
| Reflow Soldering | TSOL | 260°C ≤6s | - |
📦 Package, Dimensions & Assembly Notes
- Package: 0402 (1.0x0.5x0.4mm) SMD with clear epoxy
- SMT Compatibility: Suitable for automated placement and IR reflow soldering
- Moisture Sensitivity: MSL Level 3 (requires baking before assembly)
🚀 Sourcing & Supply Considerations
- Grading options for brightness (D2-D6), voltage (M12-6 to M13-2), and wavelength (HR02-HR03)
- EIA-standard packaging for consistent reel feeding
- Authenticity verification recommended for high-volume orders
❓ FAQ
Q: What brightness grades are available?
A: Six grades (D2-D6) from 80 to 240 mcd (IF=20mA), ±10% tolerance.
Q: Is this LED suitable for lead-free soldering?
A: Yes, compliant with IR reflow processes (max 260°C ≤6s).
Q: Can it withstand automotive temperature ranges?
A: Yes, rated for -40°C to +85°C operating temperature.
Q: What ESD protection does it offer?
A: 2000V ESD rating, suitable for handling in production.
Q: How is wavelength consistency controlled?
A: Binned into HR02 (620-625nm) and HR03 (625-630nm) ±1nm.
Q: What’s the recommended drive current?
A: Standard 20mA max continuous; 60mA peak (≤0.1ms pulse).
