📌 Product Overview
The XL-1005SURC-SA is a miniature 0402 surface-mount LED, emitting a standard red light. Designed for high-density PCB assembly, its ultra-compact footprint is ideal for applications requiring discreet yet reliable indicators. This component is engineered for seamless integration into automated SMT production lines, making it a practical choice for modern electronic design.
🔧 Typical Applications
- Automotive electronics: backlight key lights, indicator lights
- Industrial products: electronic instrument panels, industrial equipment
- Consumer electronics: LED backlights, general status indicators
- Communication products: mobile phone button lamps, routers, set-top boxes
📊 Key Technical Specifications
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Luminous Intensity | Iv | 80 | / | 240 | mcd | IF=20mA |
| Dominant Wavelength | λd | 620 | / | 630 | nm | IF=20mA |
| Peak Wavelength | λp | / | 625 | / | nm | IF=20mA |
| Forward Voltage | VF | 1.9 | / | 2.2 | V | IF=20mA |
| Viewing Angle | 2Ø1/2 | / | 120° | / | deg | IF=20mA |
⚠️ Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Value | Unit |
|---|---|---|---|
| Max Power Dissipation | PD | 50 | mW |
| Max Continuous Forward Current | IF | 20 | mA |
| Peak Forward Current | IFP | 60 | mA |
| Max Reverse Voltage | VR | 5 | V |
| Operating Temperature | TOPR | -40 to +85 | °C |
| Lead Soldering Temp/Time | TSOL | 260°C / ≤6s | / |
📦 Package, Dimensions & Assembly Notes
- Package: 0402 (1.0x0.5x0.4mm)
- Colloid: Clear/Water
- SMT Compatibility: Suitable for automated SMT placement and standard IR reflow soldering processes.
- MSL: Moisture Sensitivity Level 3. Requires standard baking and handling procedures for SMT assembly.
📈 Sourcing & Supply Considerations
- Binning: Available in brightness (D2-D6), voltage (M12-8 to M13-4), and wavelength (HR02, HR03) grades for precise application matching.
- Packaging: Supplied in EIA standard tape and reel for automated assembly.
- Compliance: RoHS compliant. Verify supply chain authenticity for critical projects.
❓ FAQ
Q: What is the brightness grading for this LED? A: The XL-1005SURC-SA is graded from D2 (80-120 mcd) to D6 (210-240 mcd) at IF=20mA, with a brightness tolerance of ±10%.
Q: Is this LED suitable for lead-free soldering processes? A: Yes, it is suitable for standard IR reflow processes, including lead-free profiles with a peak temperature not exceeding 235°C.
Q: What are the key electrical parameters to consider for design? A: Key parameters include a maximum continuous forward current of 20mA, a forward voltage of 1.9V-2.2V, and a peak forward current of 60mA (pulse width ≤0.1ms).
Q: How does the moisture sensitivity level (MSL) impact production? A: With an MSL of 3, the component requires standard SMT handling protocols, including potential baking before reflow to prevent popcorning.
Q: Can this LED be used in high-temperature automotive environments? A: The operating temperature range is -40°C to +85°C, making it suitable for many automotive electronics applications within this thermal window.
