📌 Product Overview
The XL-234UGC-L is a standard 3mm through-hole LED featuring a white water-clear colloid and a dominant wavelength of 520nm (Green). 💡 It is engineered to provide high luminous intensity—ranging from 900 to 1800 mcd—making it suitable for both status indication and low-level illumination.
This component is designed for general-purpose PCB assembly where reliable optical performance and long operating life are required. The design focuses on consistent light output and energy efficiency, driven by a low DC voltage.
🎯 Typical Applications
Based on the 110-degree viewing angle and robust thermal characteristics, the XL-234UGC-L fits the following scenarios:
- Consumer Electronics: Status indicators for home appliances and digital devices.
- Automotive Systems: Dashboard illumination and interior panel lights (non-critical).
- Industrial Indication: Traffic instructions and electronic clock displays.
- Medical & Education: Signal lights for beauty instruments and teaching equipment.
- Urban Lighting: Decorative lighting chains and city beautification projects.
📊 Key Technical Specifications
The following table outlines the electro-optical characteristics under standard test conditions (Ta=25°C, IF=20mA).
| Parameter | Symbol | Min | Typ. | Max | Unit |
|---|---|---|---|---|---|
| Luminous Intensity | Iv | 900 | 1200 | 1800 | mcd |
| Dominant Wavelength | λd | 515 | 520 | 530 | nm |
| Peak Wavelength | λp | - | 525 | - | nm |
| Forward Voltage | VF | 2.8 | 3.0 | 3.4 | V |
| Viewing Angle | 2Ø1/2 | - | 110 | - | deg |
| Reverse Current | IR | - | - | ≤10 | μA |
💡 Note: To ensure visual consistency in mass production, specific binning codes (A8/A9/B1 for brightness; N13-3 to N13-5 for voltage) should be selected during procurement.
⚠️ Absolute Maximum Ratings & Process Limits
Exceeding these ratings may cause device failure or permanent performance degradation. 👇 Design margins must account for these limits.
| Parameter | Symbol | Rating | Unit |
|---|---|---|---|
| Power Dissipation | Pd | 70 | mW |
| Max Continuous Forward Current | IF | 20 | mA |
| Peak Forward Current | IFp | 80 | mA |
| Operating Temperature | Topr | -20 to +85 | °C |
| Storage Temperature | Tstg | -40 to +85 | °C |
Soldering Limits:
- Wave Soldering: Max 240°C for ≤6s.
- Manual Welding: Max 300°C for ≤3s.
- 🔒 Critical: The soldering point must be >2.0mm from the colloid base to prevent thermal damage.
📦 Package, Dimensions & Assembly Notes
- Package Type: 3mm Radial Lead (Long leg).
- Dimensions: 3.0 (W) x 2.0 (T) x 4.0 (H) x 28 (L) mm.
- Moisture Sensitivity: MSL Level 2.
- Packaging: 1000 PCS per anti-electrostatic foil bag.
✨ Assembly Advice: The component complies with EIA standard packaging, facilitating automated feeder systems. Ensure the storage environment remains below 30°C and 70% RH to prevent moisture ingress prior to assembly.
🚀 Sourcing & Supply Considerations
- Binning Control: Verify brightness and voltage bins with the supplier if uniformity is critical for the application.
- Authenticity: Source through XINGLIGHT authorized channels to guarantee RoHS compliance and reliability standards.
- Supply Chain: Standard packaging allows for quick integration into existing CEM workflows without custom feeder adjustments.
❓ FAQ
Q: What is the forward voltage requirement for this LED? A: The typical forward voltage is 3.0V, with a maximum of 3.4V at 20mA. Ensure your driving circuit can supply at least 3.4V to account for tolerance variations.
Q: Can this LED be used for outdoor lighting? A: While it is used in urban lighting, the operating temperature range is -20°C to +85°C. For extreme outdoor environments, additional waterproofing and thermal management are required.
Q: What does MSL Level 2 mean for assembly? A: Moisture Sensitivity Level 2 means the components can be exposed to the factory floor for up to one year (at <30°C/85% RH) before baking is required prior to soldering.
Q: How is the brightness sorted? A: Brightness is sorted into grades A8 (900-1200 mcd), A9 (1200-1500 mcd), and B1 (1500-1800 mcd). Specify the required grade when placing orders to ensure consistency.
