📌 Product Overview
The XL-1005UOC is a miniature, surface-mount LED from XINGLIGHT, designed for applications requiring a compact footprint and reliable performance. Its 1.0x0.5x0.40mm outline makes it ideal for space-constrained designs. The device emits a bright orange light through a transparent package, serving as a visual indicator or status light. It is engineered for seamless integration into automated SMT assembly processes, making it a practical choice for mass production environments.
💡 Typical Applications
- Automotive Electronics: Backlight for control keys and status indicator lights
- Industrial Products: Instrument panels and control units for machinery
- Consumer Electronics: Status indicators on home appliances and personal devices
- Communication Equipment: LED indicators for routers, set-top boxes, and mobile phones
- General Electronics: Backlighting and status indication in various digital devices
🔑 Key Technical Specifications
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Luminous Intensity | Iv | 80 | / | 210 | mcd | IF=20mA |
| Dominant Wavelength | λd | 600 | / | 610 | nm | IF=20mA |
| Forward Voltage | VF | 1.9 | / | 2.2 | V | IF=20mA |
| Viewing Angle | 2Ø1/2 | / | 120° | / | deg | IF=20mA |
🔒 Absolute Maximum Ratings & Process Limits
Electrical and thermal operating limits must be strictly adhered to for device reliability. Exceeding these ratings can cause permanent damage. Key parameters include a maximum continuous forward current (IF) of 20 mA and a peak pulse current (IFP) of 60mA. The device is rated for an operating temperature range of -40°C to +85°C. For assembly, the soldering temperature must not exceed 260°C for more than 6 seconds.
| Parameter | Symbol | Value | Unit |
|---|---|---|---|
| Max Continuous Forward Current | IF | 20 | mA |
| Peak Forward Current | IFP | 60 | mA |
| Operating Temperature | TOPR | -40 to +85 | °C |
| Soldering Temp./Time | TSOL | 260°C / ≤6s | / |
📦 Package, Dimensions & Assembly Notes
The XL-1005UOC utilizes a standard SMD package with outline dimensions of 1.0mm (L) x 0.5mm (W) x 0.4mm (H). It is compliant with EIA standard packaging and has a Moisture Sensitivity Level (MSL) of 3. The device is specifically designed for automated SMT assembly and is fully compatible with standard reflow soldering processes, ensuring high throughput and yield in manufacturing.
🚀 Sourcing & Supply Considerations
When sourcing the XL-1005UOC, verify supply chain authenticity to avoid counterfeit components. Request samples for initial design validation and functional testing. For mass production, confirm lead-time and minimum order quantity (MOQ) with the authorized distributor. Ensure the component's RoHS compliance aligns with your product's environmental regulations.
❓ FAQ
Q: What is the brightness grading for the XL-1005UOC? A: The luminous intensity is graded into five bins (D2 to D5) ranging from a minimum of 80 mcd to a maximum of 210 mcd, with a tolerance of ±10%.
Q: Is the XL-1005UOC suitable for lead-free soldering processes? A: Yes, the device is compatible with both lead and lead-free reflow soldering profiles, with specific temperature and time limits provided in the datasheet to ensure reliability.
Q: What is the Moisture Sensitivity Level (MSL) for this LED? A: The XL-1005UOC has an MSL rating of 3, which requires standard baking and handling procedures before SMT assembly to prevent moisture-induced damage during reflow.
Q: Can this LED be used in high-temperature automotive environments? A: Yes, its operating temperature range of -40°C to +85°C makes it suitable for many automotive applications, but final validation should be performed against specific automotive standards.
