📌 Product Overview
The XL-1010SURUGC is a miniature surface-mount LED designed for high-density PCB integration. Its dual red/green emission and ultra-compact footprint (1.0x1.0x0.4mm) make it ideal for space-constrained applications. The device supports automated SMT assembly and infrared reflow soldering, ensuring compatibility with modern manufacturing processes while maintaining RoHS compliance.
🔍 Typical Applications
- Automotive instrument clusters
- Smart home control panels
- Bluetooth audio status indicators
- Backlight displays for consumer electronics
- Healthcare monitoring equipment
📊 Key Technical Specifications
| Parameter | Symbol | Red (Min/Typ/Max) | Green (Min/Typ/Max) | Unit |
|---|---|---|---|---|
| Luminous Intensity | IV | 80//210 | 550//1000 | mcd |
| Dominant Wavelength | λD | 615//630 | 515//530 | nm |
| Forward Voltage | VF | 1.9//2.3 | 2.6//3.4 | V |
| Half Light Angle | 2θ1/2 | //120 | //120 | deg |
⚠️ Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Value | Unit |
|---|---|---|---|
| Max Power Dissipation | PD | 50 (R) / 70 (G) | mW |
| Max Continuous Forward Current | IF | 20 | mA |
| Peak Forward Current | IFP | 60 (R) / 80 (G) | mA |
| Operating Temperature | TOPR | -40 to +85 | °C |
| Soldering Temp/Time | TSOL | 260°C ≤ 6s | - |
📦 Package, Dimensions & Assembly Notes
The XL-1010SURUGC uses EIA-standard tape-and-reel packaging for SMT automation. Key assembly notes:
- Moisture Sensitivity Level (MSL): 3
- Suitable for IR reflow (lead-free: 255°C max; leaded: 235°C max)
- Thermal profile: ≤3°C/s ramp rate, ≤6°C/s cooling
🚀 Sourcing & Supply Considerations
- Brightness/voltage/wavelength binning available (e.g., D5, N13-3, HR02)
- RoHS-compliant manufacturing ensures regulatory compliance
- ESD protection (2000V) reduces handling risks
❓ FAQ
Q: What is the typical brightness bin for high-intensity green LEDs?
A: The E9 bin offers 900–1000 mcd at 20mA.
Q: Is this LED suitable for automotive-grade applications?
A: Its operating range (-40 to +85°C) and AEC-Q102-compliant testing support automotive use.
Q: How does MSL 3 affect storage?
A: Requires dry storage (<30% RH) and baking (125°C, 24h) if exposed >72h.
Q: Can it withstand lead-free reflow processes?
A: Yes, with peak temperature ≤255°C and dwell time 5–10s.
Q: What’s the dominant wavelength tolerance?
A: ±1 nm (e.g., HR02: 620–625 nm for red).
Q: Are there alternative packages available?
A: Consult XINGLIGHT for custom binning or alternative footprints.
```
