📌 Product Overview
The XL-1010SURSYGC is a surface-mount LED from XINGLIGHT, featuring a miniature footprint ideal for space-constrained designs. This dual-color (Red/Green) device with a transparent colloid is engineered for high-volume manufacturing, specifically compatible with SMT assembly and infrared reflow processes. Its primary focus is on providing reliable visual indicators and backlighting in modern electronic products.
🔍 Typical Applications
- Backlight displays for consumer electronics
- Status indicators in household appliances
- Instrument panels in automotive applications
- Visual feedback in Bluetooth audio equipment
- Decorative elements in lighting fixtures
- Integration in smart home devices
📊 Key Technical Specifications
| Parameter | Symbol | Red | Green | Unit | Test Condition |
|---|---|---|---|---|---|
| Luminous Intensity | IV | 80 / 210 | 50 / 80 | mcd | IF=20mA |
| Dominant Wavelength | λD | 615 / 630 | 565 / 575 | nm | IF=20mA |
| Forward Voltage | VF | 1.9 / 2.3 | 1.9 / 2.3 | V | IF=20mA |
| Half Intensity Angle | 2θ1/2 | / 120 / | / 120 / | deg | IF=20mA |
⚠️ Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Value | Unit |
|---|---|---|---|
| Max Power Dissipation | PD | 50 | mW |
| Max Continuous Forward Current | IF | 20 | mA |
| Max Peak Forward Current | IFP | 60 | mA |
| Max Reverse Voltage | VR | 5 | V |
| Operating Temperature | TOPR | -40 to +85 | °C |
| Lead Soldering Temp/Time | TSOL | 260℃ / ≤6s | / |
📦 Package, Dimensions & Assembly Notes
The XL-1010SURSYGC utilizes an ultra-compact package measuring 1.0x1.0x0.4mm (L/W/H). It is classified as MSL 3 and is suitable for SMT automated production. The device is compliant with EIA standard packaging and designed for compatibility with infrared reflow soldering, ensuring robust performance in standard manufacturing environments.
🚀 Sourcing & Supply Considerations
- Sample Support: Request samples to validate optical and electrical binning requirements for your specific application.
- Volume Production: Confirm lead-times and minimum order quantities for mass production quantities.
- Supply Chain: Verify distribution channels to ensure authenticity and avoid counterfeit components.
- Alternatives: Consider cross-referencing with similar models for BOM optimization or risk mitigation.
❓ FAQ
Q: What is the moisture sensitivity level (MSL) for the XL-1010SURSYGC?
A: The device has a Moisture Sensitivity Level (MSL) of 3, requiring careful handling and baking procedures before soldering if exposed to ambient conditions for an extended period.
Q: What is the recommended soldering profile for this LED?
A: The XL-1010SURSYGC is suitable for infrared reflow processes. For lead-free soldering, the peak temperature should not exceed 255°C, with a dwell time of 5-10 seconds. For leaded processes, the peak temperature is 235°C with a 10-15 second dwell.
Q: How is the brightness graded for the red version of this LED?
A: The red LED's luminous intensity is graded into five bins (D1-D5) at IF=20mA, ranging from a minimum of 50 mcd (D1) to a maximum of 210 mcd (D5), with a typical brightness of 210 mcd.
Q: Can this LED be used in high-temperature automotive environments?
A: While the operating temperature range is -40°C to +85°C, use in automotive applications requires careful evaluation against specific AEC-Q102 or other relevant automotive reliability standards, as this datasheet does not explicitly state AEC compliance.
