📌 Product Overview
The XL-3014YWC-02 from XINGLIGHT is a surface-mount device (SMD) LED designed for high-density lighting arrays. Housed in a compact 3.0 x 1.4 x 0.8 mm package with a yellow colloid, it emits a warm golden light (1500K–1900K). 💡 It is engineered for environments requiring robust thermal performance and consistent luminous intensity.
💡 Target applications range from LCD backlights to commercial signage. Designers should focus on the component's 60 mA drive current and 120-degree viewing angle to maximize optical efficiency in tight spaces. This component ensures reliability in both indoor and automotive auxiliary lighting scenarios.
🎯 Typical Applications
Based on the XL-3014YWC-02's optical and thermal characteristics, it is best suited for the following use cases:
- Indoor Illumination: Ideal for light tubes and strips where uniform golden light is required.
- Commercial Signage: 📈 High-intensity output (up to 23 LM) ensures visibility in advertising boards.
- LCD Backlights: Provides consistent color temperature for display enhancement.
- Decorative Lighting: Suitable for metal plate hard light strips requiring a compact form factor.
- Automotive Interiors: 🚗 Meets reliability standards for auxiliary cabin lighting.
⚡ Key Technical Specifications
The table below outlines the critical optical and electrical parameters ($T_a = 25^\circ C$).
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Test Conditions |
|---|---|---|---|---|---|---|
| Luminous Intensity | $\Phi$ | 13 | - | 23 | LM | $I_F = 60 \text{ mA}$ |
| Color Temperature | $T_C$ | 1500 | - | 1900 | K | $I_F = 60 \text{ mA}$ |
| Forward Voltage | $V_F$ | 2.8 | - | 3.4 | V | $I_F = 60 \text{ mA}$ |
| Viewing Angle | $2\theta_{1/2}$ | - | 120 | - | Deg | $I_F = 60 \text{ mA}$ |
| Reverse Current | $I_R$ | - | - | 5 | $\mu$A | $V_R = 5 \text{ V}$ |
💡 Design Note: The component is sorted by brightness (H8-J1) and voltage (N13-3 to N13-5), allowing for precise bin selection in uniform arrays.
⚠️ Absolute Maximum Ratings & Process Limits
Exceeding these ratings may cause permanent damage. 🔒 Reliability depends on strictly adhering to these limits ($T_a = 25^\circ C$).
| Parameter | Symbol | Max. Value | Unit | Notes |
|---|---|---|---|---|
| Max Power Dissipation | $P_D$ | 200 | mW | - |
| Max Forward Current | $I_F$ | 60 | mA | DC Continuous |
| Peak Forward Current | $I_{FP}$ | 120 | mA | Pulse $\le 0.1\text{ms}$, Duty $\le 1/10$ |
| Max Reverse Voltage | $V_R$ | 5 | V | - |
| ESD Ability | ESD | 2000 | V | Human Body Model (HBM) |
| Operating Temp. | $T_{OPR}$ | -40 ~ +85 | $^\circ$C | - |
| Storage Temp. | $T_{STR}$ | -40 ~ +85 | $^\circ$C | - |
⚠️ Critical Warning: Soldering temperature must not exceed 260°C for 6 seconds.
📦 Package, Dimensions & Assembly Notes
- Package Type: 3014 SMD (3.0 x 1.4 x 0.8 mm).
- Moisture Sensitivity: 🌧️ MSL Level 3. Ensure proper baking before reflow if exposed to ambient humidity.
- Soldering Process: Compatible with Infrared Reflow. For lead-free processes, peak body temperature should not exceed 255°C (max 6°C/sec ramp down).
- Assembly: Designed for SMT automatic production and EIA standard packaging tapes.
🚀 Sourcing & Supply Considerations
- Authenticity Verification: Always procure through authorized XINGLIGHT channels to avoid counterfeits.
- Sample Support: Request specific bin codes (e.g., YW4-4 for 1500K-1700K) to match prototype requirements.
- Lead Time: Check availability for high-volume commercial lighting orders to prevent production delays.
- Technical Consultation: Contact LDeepAI for application notes or alternative sourcing options.
❓ Frequently Asked Questions
Q: What is the forward voltage range for this LED at 60 mA? A: The forward voltage ($V_F$) ranges from 2.8V to 3.4V at the rated current of 60 mA. It is binned into codes N13-3 (2.8-3.0V), N13-4 (3.0-3.2V), and N13-5 (3.2-3.4V) for tighter circuit design control.
Q: Can the XL-3014YWC-02 be used in outdoor environments? A: While the storage and operating temperatures range from -40°C to +85°C, this model is primarily designed for indoor and commercial lighting. For outdoor use, ensure the final fixture provides adequate IP protection against water ingress.
Q: What are the soldering profile requirements for lead-free assembly? A: For lead-free processes, the max peak temperature is 255°C. The ramp-up rate should be under 3°C/sec, and time above 217°C should be limited to 60-120 seconds. 🔒 Ensure the cooling rate does not exceed 6°C/sec.
Q: How is the color temperature consistency managed? A: XINGLIGHT bins these LEDs by color temperature. Code YW4-4 covers 1500K-1700K, and YW6-4 covers 1700K-1900K. Selecting the correct bin code is crucial for uniform color appearance in light strips.
Q: What is the moisture sensitivity level (MSL) and floor life? A: The component has an MSL of 3. This means it can be exposed to the factory floor for 168 hours (one week) after the vacuum seal is broken before it requires baking to prevent popcorning damage during reflow.
Q: Is this component suitable for high-intensity automotive lighting? A: It is rated for auxiliary interior lighting (up to 60 mA). It is not designed for exterior headlight applications, which typically require higher power and stricter thermal management.
