ð Product Overview
The XINGLIGHT XL-3014WWC-02 is a high-performance Surface Mount Device (SMD) LED designed for space-constrained lighting applications. ð Featuring a compact 3.0x1.4x0.8mm outline, this component utilizes a yellow colloid to produce a stable Warm White light, making it ideal for indoor and commercial fixtures. ðĄ While the primary function is illumination, the real design focus lies in its compatibility with automated SMT processes and infrared reflow soldering, ensuring consistent quality in high-volume production environments.
ð Typical Applications
This versatile LED component is engineered for a wide range of lighting scenarios, particularly where compact size and warm color temperature are required. Based on its specifications, the XL-3014WWC-02 is best suited for:
- Indoor Lighting: ð Ideal for lamp tubes and flexible light strips requiring a cozy atmosphere.
- Commercial Display: ðĒ Used in advertising boards and signage where uniform warm light is essential.
- LCD Backlighting: ðš Provides efficient backlighting for display panels.
- Decorative Lighting: âĻ Suitable for rigid light strips on metal plates.
- Automotive Interiors: ð Supports auxiliary lighting functions within vehicle cabins.
ð Key Technical Specifications
To ensure proper integration, engineers must reference the optical and electrical performance under standard test conditions (Ta=25â).
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Test Conditions |
|---|---|---|---|---|---|---|
| Luminous Flux | ÎĶ | 20 | - | 33 | LM | IF = 60mA |
| Color Temperature | TC | 2800 | - | 3200 | K | IF = 60mA |
| Forward Voltage | Vf | 2.8 | - | 3.4 | V | IF = 60mA |
| Viewing Angle | 2Îļ1/2 | - | 120 | - | Deg | IF = 60mA |
| Reverse Current | Ir | - | - | 5 | ΞA | VR = 5V |
â ïļ Note: The product is sorted into specific bins (J1-J3 for brightness, N13 for voltage) to ensure consistency in your design.
ð Absolute Maximum Ratings & Process Limits
Exceeding these ratings may cause permanent damage to the device or significantly reduce its lifespan. These limits are critical for designing robust protection circuits.
| Parameter | Symbol | Value | Unit | Notes |
|---|---|---|---|---|
| Max Power Dissipation | PD | 200 | mW | - |
| Max Forward Current | IF | 60 | mA | Continuous DC |
| Peak Forward Current | IFP | 120 | mA | Pulse width âĪ0.1ms, Duty âĪ1/10 |
| Max Reverse Voltage | VR | 5 | V | - |
| ESD Ability | ESD | 2000 | V | Human Body Model (HBM) |
| Operating Temperature | TOPR | -40 ~ +85 | â | - |
| Storage Temperature | TSTR | -40 ~ +85 | â | - |
ðĄ Design Tip: Ensure the drive current stays within the 60mA limit to maintain thermal stability, especially in high-density arrays.
ð ïļ Package, Dimensions & Assembly Notes
The XL-3014WWC-02 comes in standard EIA compliant packaging, optimized for automated assembly.
- Dimensions: The physical body size is strictly 3.0mm (L) x 1.4mm (W) x 0.8mm (H). ð
- Soldering: It is suitable for Infrared Reflow Soldering. For lead-free processes, the peak temperature should not exceed 255â (max 6â/s ramp down).
- Moisture Sensitivity: The component is classified as MSL Level 3. Floor life at <30â/60% RH is 168 hours.
- Process Compatibility: Designed for SMT automatic production, ensuring rapid placement speeds.
ð Sourcing & Supply Considerations
When integrating the XL-3014WWC-02 into your BOM, consider the following supply chain factors:
- Bin Selection: Verify specific bin codes (Brightness J1-J3, Voltage N13, Color Temp WW2-4/WW4-4) with your supplier to match optical requirements.
- Packaging: Confirm EIA standard tape and reel specifications to fit your pick-and-place machines.
- Authenticity: Source exclusively through authorized XINGLIGHT channels to avoid counterfeit components that compromise reliability.
- Samples: Request engineering samples for prototype testing before full-scale production commitment.
â FAQ
Q: What is the forward voltage range for this LED at 60mA?
A: The forward voltage (Vf) typically ranges from 2.8V to 3.4V when driven at 60mA. It is essential to check the specific voltage grade (N13-3, N13-4, or N13-5) to match your driver circuit.
Q: Can this LED be used with a lead-free soldering process?
A: Yes, the XL-3014WWC-02 is compatible with lead-free infrared reflow soldering. The maximum recommended peak temperature is 255â, with a time duration of 5-10 seconds above peak.
Q: What does "MSL Level 3" mean for my production line?
A: MSL (Moisture Sensitivity Level) 3 means the components can be exposed to ambient air (âĪ30â / 60% RH) for 168 hours after opening the vacuum seal before they must be soldered to prevent moisture-induced damage (popcorning).
Q: What is the typical viewing angle of the light emitted?
A: The viewing angle (2Îļ1/2) is 120 degrees. This wide angle makes it suitable for general lighting and backlighting applications where broad light distribution is desired.
Q: How should I handle the component regarding ESD protection?
A: The device has an antistatic ability of 2000V. While it offers some protection, standard ESD precautions (wrist straps, grounded mats) are always recommended during handling and assembly.
