📌 Product Overview
The XL-0807RGBC-MS is a miniature surface-mount (SMT) RGB LED featuring a built-in flashing function, housed in a clear 2.0x1.8x0.8mm package. Designed for automated assembly, it supports standard reflow soldering and complies with RoHS standards. Its compact size and RGB output make it ideal for applications requiring dynamic, low-profile illumination, particularly where space and manufacturing efficiency are critical.
🚀 Typical Applications
- Channel lettering and signage
- Advertising lightboxes
- Decorative lighting fixtures
- Specialized apparel and crafts
- Architectural accent lighting
🔍 Key Technical Specifications
| Parameter | Symbol | Min | Typ | Max | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Working Voltage | VF | 3.0 | - | 4.5 | V | - |
| Luminous Intensity | Iv | - | 130 | - | mcd | R: IF=20mA |
| - | 750 | - | mcd | G: IF=20mA | ||
| - | 200 | - | mcd | B: IF=20mA | ||
| Dominant Wavelength | λd | - | 620 | - | nm | R: IF=20mA |
| - | 515 | - | nm | G: IF=20mA | ||
| - | 465 | - | nm | B: IF=20mA | ||
| Half Light Angle | 2θ1/2 | - | 120 | - | Deg | IF=20mA |
| Flicker Period | T | - | 35 | - | S | IF=20mA |
⚠️ Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Value | Unit | Condition |
|---|---|---|---|---|
| Max Continuous Forward Current | IF | 20 | mA | R/G/B |
| Max Peak Forward Current | IFP | 80 | mA | R/G/B (Pulse ≤0.1ms) |
| Max Reverse Voltage | VR | 5 | V | - |
| Operating Temperature | TOPR | -40~85 | °C | - |
| Reflow Soldering Temp/Time | TSOL | 260°C | ≤6s | - |
| Antistatic Ability | ESD | 2000 | V | - |
📦 Package, Dimensions & Assembly Notes
The XL-0807RGBC-MS is packaged in a compact 2.0x1.8x0.8mm SMT outline with a clear epoxy colloid. It is moisture-sensitive (MSL-3) and requires EIA-standard packaging for automated production. Suitable for standard reflow soldering processes, with a peak temperature limit of 260°C for ≤6 seconds. Ensure proper handling and baking before assembly to prevent moisture-related defects.
📈 Sourcing & Supply Considerations
- Verify MSL-3 compliance and dry-pack storage to avoid soldering defects.
- Lead times may vary; confirm stock with authorized distributors for large orders.
- Cross-check optical binning requirements for consistent color output in production.
- Request samples to validate reflow profile compatibility with existing processes.
❓ FAQ
Q: What is the flicker period of the XL-0807RGBC-MS?
A: The typical flicker period is 35 seconds at IF=20mA.
Q: Is this LED suitable for lead-free soldering?
A: Yes, it supports standard lead-free reflow profiles with a peak temperature of 260°C for ≤6 seconds.
Q: What is the moisture sensitivity level?
A: The XL-0807RGBC-MS has an MSL of 3, requiring careful handling and baking before assembly.
Q: Can it withstand high-temperature storage?
A: Yes, it can be stored at temperatures up to +85°C per JIS C 7021:B-10.
Q: What are the peak current limits?
A: The maximum peak forward current (IFP) is 80mA for R/G/B channels, with a pulse width ≤0.1ms and duty cycle ≤1/10.
Q: Is RoHS compliance guaranteed?
A: Yes, the XL-0807RGBC-MS is manufactured in accordance with RoHS directive requirements.
```
