📌 Product Overview
The XL-0807RGBC-KS is a surface-mountable (SMT) LED featuring a compact 0807 package (2.0x1.8x0.8mm) with integrated RGB color flashing functionality. Its transparent epoxy colloid provides vibrant light output. Designed for automated manufacturing, it is suitable for high-volume applications requiring dynamic, multi-color visual effects in a miniature footprint.
🔧 Typical Applications
- Channel lettering and dimensional signage
- Advertising lightboxes and illuminated displays
- Decorative lighting for architectural features
- Specialized apparel and costume illumination
- Arts, crafts, and novelty lighting projects
📊 Key Technical Specifications
| Parameter | Symbol | Rating (Typical) | Unit | Test Condition |
|---|---|---|---|---|
| Forward Voltage | VF | 3.0 - 4.5 | V | / |
| Luminous Intensity | Iv | R: 100-155 G: 600-800 B: 132-223 | mcd | IF=20mA |
| Dominant Wavelength | λd | R: 620-625 G: 515-525 B: 465-475 | nm | IF=20mA |
| Viewing Angle | 2θ1/2 | 120 | Deg | IF=20mA |
| Flicker Period | T | 15 | S | IF=20mA |
⚠️ Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Value | Unit |
|---|---|---|---|
| Max Power Dissipation | PD | R: 50 G/B: 70 | mW |
| Max Continuous Forward Current | IF | R/G/B: 20 | mA |
| Max Peak Forward Current | IFP | R/G/B: 80 | mA |
| Max Reverse Voltage | VR | 5 | V |
| Operating Temperature | TOPR | -40 to +85 | °C |
| ESD Protection | ESD | 2000 | V |
| Reflow Soldering | TSOL | 260°C ≤ 6s | / |
📦 Package, Dimensions & Assembly Notes
The XL-0807RGBC-KS utilizes a standard 0807 (2.0x1.8x0.8mm) SMD package with a transparent colloid. It is compliant with EIA standard packaging and has a Moisture Sensitivity Level (MSL) of 3. The device is specifically designed for automated SMT assembly and is fully compatible with standard IR reflow soldering processes for both leaded and lead-free solder pastes.
🚀 Sourcing & Supply Considerations
- Sample & Volume: Request samples for initial optical and thermal validation.
- Authenticity: Source exclusively from authorized XINGLIGHT distributors to guarantee specification compliance.
- Lead Time: Confirm production lead times for high-volume orders to prevent BOM delays.
❓ FAQ
Q: What is the primary application for the XL-0807RGBC-KS?
A: It is designed for applications requiring compact, dynamic RGB lighting, such as channel lettering, signs, and decorative displays.
Q: What is the maximum soldering temperature for this LED?
A: The peak reflow temperature must not exceed 260°C for a duration of 6 seconds or less.
Q: Is this LED suitable for automated SMT assembly?
A: Yes, it is designed for SMT production and is compatible with standard reflow soldering processes.
Q: What is the flicker rate of the RGB flashing function?
A: The typical flicker period is 15 seconds.
Q: What is the Moisture Sensitivity Level (MSL)?
A: The MSL is 3, requiring standard baking and handling procedures before SMT assembly.
Q: Can this LED withstand high-temperature storage conditions?
A: Yes, it can be stored at temperatures up to +85°C.
