📌 Product Overview
The XINGLIGHT XL-1005UGC-A is a miniature surface-mount LED (SMD) packaged in a compact 0402 outline (1.0x0.5x0.40mm). It is engineered for applications requiring high-intensity green illumination and seamless integration into automated SMT assembly lines. The device is designed for reliability in demanding environments, making it a suitable choice for designers working on space-constrained and high-performance electronic products.
🔍 Typical Applications
- Automotive Electronics: Backlighting for keypads and indicator lights
- Industrial Products: Instrument panels and control equipment
- Consumer Electronics: Status indicators and backlighting modules
- Communication Devices: Mobile phone keypads, routers, and set-top boxes
- Digital Devices: Internal indicators for computers and mobile phones
📊 Key Technical Specifications
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Luminous Intensity | Iv | 550 | / | 1450 | mcd | IF=20mA |
| Dominant Wavelength | λd | 515 | / | 535 | nm | IF=20mA |
| Peak Wavelength | λp | / | 525 | / | nm | IF=20mA |
| Forward Voltage | VF | 2.6 | / | 3.3 | V | IF=20mA |
| Viewing Angle | 2Ø1/2 | / | 120° | / | deg | IF=20mA |
⚠️ Absolute Maximum Ratings & Process Limits
Electrical and thermal parameters that must not be exceeded under any operating conditions. Adhering to these limits is critical for device reliability and preventing catastrophic failure.
| Parameter | Symbol | Value | Unit |
|---|---|---|---|
| Max Continuous Forward Current | IF | 20 | mA |
| Max Peak Forward Current | IFP | 80 | mA |
| Max Reverse Voltage | VR | 5 | V |
| Operating Temperature Range | TOPR | -40 ~ +85 | °C |
| Lead Soldering Temp/Time | TSOL | 260℃ / ≤6s | / |
📦 Package, Dimensions & Assembly Notes
The XL-1005UGC-A utilizes a compact 0402 SMD package with dimensions of 1.0x0.5x0.40mm. It is compliant with EIA standard packaging for automated placement. The device is suitable for standard reflow soldering processes and has a Moisture Sensitivity Level (MSL) of 3, requiring standard bake and handling procedures before assembly to prevent popcorning.
🚀 Sourcing & Supply Considerations
- Binning Options: Available in brightness (E5-F3), voltage (M18-8 to M19-5), and wavelength (HG02-HG05) grades for precise application matching.
- Supply Chain: RoHS-compliant manufacturing ensures environmental standard adherence.
- Verification: For sample requests, production lead times, and authenticity verification, please contact our technical support team.
❓ FAQ
Q: What is the typical luminous intensity for the XL-1005UGC-A? A: The typical luminous intensity is graded from 550 mcd to 1450 mcd at IF=20mA, with codes ranging from E5 to F3.
Q: What is the recommended soldering profile for this LED? A: The XL-1005UGC-A is suitable for standard reflow soldering. The peak temperature must not exceed 260°C for a duration of 6 seconds or less. For lead-free processes, the maximum temperature is 255°C.
Q: What is the Moisture Sensitivity Level (MSL)? A: The MSL is 3, which means it must be handled according to standard moisture-sensitive component procedures, including baking if exposed to ambient conditions for an extended period.
Q: Can this LED be used in automotive applications? A: Yes, it is listed for automotive applications such as backlight key lights and indicators, but final qualification should be performed to meet specific AEC-Q standards for the end-use environment.
Q: What are the main wavelength options available? A: The dominant wavelength is available in 5nm bins, ranging from 515nm to 535nm (codes HG02 to HG05), allowing for color consistency in specific applications.
