🚀 XL-1010RGBC-WS2812B-S: 1010 SMD LED with Integrated Constant Current IC for High-Density Lighting
📌 Product Overview
The XL-1010RGBC-WS2812B-S is a miniature 1.0x1.0x0.8mm SMD LED integrating a high-precision constant current IC and RGB chips. It supports single-wire data transmission and is optimized for automated SMT assembly. The device targets applications requiring compact form factors and consistent color performance, such as addressable LED displays and decorative lighting.
💡 Typical Applications
- LED full-color luminous word lamp strings
- LED modules and soft/hard light strips
- LED guardrail tubes and scene lighting
- Heterogeneous LED screens
- Running lights for electronics and appliances
🔧 Key Technical Specifications
| Parameter | Symbol | Min | Typ | Max | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Output Current | Iout | - | 5 | - | mA | VDD=5V, VDS=1V |
| PWM Grayscale | - | - | 256 | - | levels | - |
| Data Frequency | - | - | 800 | - | Kbps | - |
| Half Intensity Angle | 2θ1/2 | - | 120 | - | Deg | - |
⚠️ Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Min | Max | Unit | Condition |
|---|---|---|---|---|---|
| Supply Voltage | VDD | 3.5 | 5.5 | V | Ta=25℃ |
| Operating Temp | Topr | -40 | 85 | ℃ | - |
| Reflow Temp | Tsol | - | 260 | ℃ | 6s |
| ESD Rating | ESD | - | 2000 | V HBM | - |
📦 Package, Dimensions & Assembly Notes
- Package: 1010 SMD (1.0x1.0x0.8mm)
- MSL: Level 5 (requires moisture protection)
- SMT Compatibility: Suitable for infrared reflow soldering
- Assembly Notes: Pre-drying recommended for MSL compliance; EIA-standard packaging for automated production.
🔍 Sourcing & Supply Considerations
- Authenticity verification required due to high counterfeit risk
- Lead times may vary with ROHS compliance status
- Sample support available for prototype validation
- Cross-referencing advised for BOM optimization
❓ FAQ
Q: What is the maximum cascading count for this LED?
A: Supports >1024 LEDs at 30fps refresh rate with 800Kbps data transmission.
Q: Is constant current precision guaranteed across batches?
A: Yes, with intraslice error <1.5% and interslice error <3%.
Q: Can it operate at 3.3V logic levels?
A: No, minimum VDD is 3.5V, with VIH at 0.7VDD.
Q: What’s the recommended soldering profile?
A: IR reflow at 260°C for 6 seconds max, per EIA standards.
Q: Is this LED suitable for outdoor use?
A: Operating temperature range (-40°C to 85°C) supports outdoor applications with proper sealing.
```
