📌 Product Overview
The XL-3014BGWC-02 is a specialized Ice Blue SMD LED from XINGLIGHT, designed to balance luminous intensity with compact integration. ✨ Housed in a 3.0x1.4x0.8mm package, this component is engineered for modern SMT automatic production lines, offering a reliable light source for constrained spaces.
💡 While the nominal 8-13lm brightness is suitable for indicators and auxiliary lighting, the real design focus lies in its thermal and electrical stability. With a forward voltage range of 2.8V-3.4V and ROHS compliance, it serves as a robust solution for commercial lighting and LCD backlights where consistent color temperature (Ice Blue) and longevity are critical.
🚀 Typical Applications
Based on the provided datasheet parameters, the XL-3014BGWC-02 is optimized for the following scenarios:
- Indoor Lighting: Ideal for lamp tubes and flexible light strips requiring low-profile components.
- Commercial Signage: Suitable for advertising boards and information displays.
- LCD Backlights: Provides uniform Ice Blue illumination for display panels.
- Decorative Lighting: Used in metal plate hard light strips for accent lighting.
- Automotive Interiors: Designed for auxiliary lighting inside vehicles, leveraging its wide viewing angle.
📈 Key Technical Specifications
The performance of the XL-3014BGWC-02 is defined by its optical and electrical characteristics under standard test conditions (Ta=25°C).
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Test Conditions |
|---|---|---|---|---|---|---|
| Luminous Intensity | Φ | 8 | — | 13 | lm | IF = 60mA |
| Forward Voltage | VF | 2.8 | — | 3.4 | V | IF = 60mA |
| Color Rendering Index | Ra | — | 70 | — | — | IF = 60mA |
| Viewing Angle | 2θ1/2 | — | 120 | — | Deg | IF = 60mA |
| Reverse Current | Ir | — | — | 5 | μA | VR = 5V |
| Chromaticity (x) | X | — | 0.18 | — | — | IF = 60mA |
| Chromaticity (y) | Y | — | 0.17 | — | — | IF = 60mA |
💡 Design Insight: The wide 120-degree viewing angle ensures broad light distribution, essential for backlighting and strip lighting applications.
🔒 Absolute Maximum Ratings & Process Limits
To ensure reliability and prevent catastrophic failure, designers must strictly adhere to these absolute maximum ratings (Ta=25°C).
| Parameter | Symbol | Max. Value | Unit | Notes |
|---|---|---|---|---|
| Max Power Dissipation | PD | 200 | mW | Derate above 25°C |
| Max Forward Current | IF | 60 | mA | Continuous DC |
| Peak Forward Current | IFP | 120 | mA | Pulse width ≤0.1ms, Duty ≤1/10 |
| Max Reverse Voltage | VR | 5 | V | — |
| ESD Ability | ESD | 2000 | V | Human Body Model |
| Operating Temp. | TOPR | -40 ~ +85 | °C | — |
| Storage Temp. | TSTR | -40 ~ +85 | °C | — |
⚠️ Critical Warning: Exceeding the 60mA continuous forward current or the 200mW power dissipation limit will significantly degrade the LED lifespan or cause immediate failure.
🛠️ Package, Dimensions & Assembly Notes
The physical design of the XL-3014BGWC-02 facilitates automated assembly but requires specific handling during the soldering process.
- Dimensions: The compact footprint measures 3.0 x 1.4 x 0.8mm, allowing for high-density placement on PCBs.
- Moisture Sensitivity: The component is classified as MSL 3. 💡 Crucial Step: Baking is required before opening if the floor life has been exceeded to prevent "popcorning" during reflow.
- Soldering Process:
- Lead-Free: Max temp 260°C, time ≤10s (above 217°C: 60-120s).
- With Lead: Max temp 235°C, time ≤15s (above 183°C: 60-150s).
- Manual Soldering: Max 260°C for ≤6 seconds.
- Packaging: Complies with EIA standard packaging for seamless feeder setup in SMT machines.
📦 Sourcing & Supply Considerations
When integrating the XL-3014BGWC-02 into your supply chain, consider these critical factors to ensure production continuity.
- Bin Selection: Verify the specific Brightness (H6/H7) and Voltage (N13-3/4/5) bins with your supplier to ensure uniformity across large installations.
- Authenticity: Source exclusively through authorized XINGLIGHT channels to guarantee ROHS compliance and avoid counterfeits that fail thermal stress tests.
- Sample Evaluation: Always request samples from the specific production batch to validate the Ice Blue color coordinates against your design requirements.
- MSL Handling: Confirm that your supplier has stored the components correctly to maintain the MSL 3 integrity prior to delivery.
❓ FAQ
Q: What is the maximum current I can drive the XL-3014BGWC-02 with? A: The maximum continuous forward current is 60mA. While a pulsed current up to 120mA is allowed, it requires a pulse width ≤0.1ms and a duty cycle ≤1/10.
Q: Can this LED be used for outdoor lighting applications? A: The datasheet specifies operating temperatures up to +85°C. While suitable for enclosed fixtures, it is primarily categorized for Indoor, Commercial, and Automotive Interior lighting. For outdoor use, ensure the IP rating of the final fixture protects the component from moisture ingress, as the LED itself is MSL 3 sensitive.
Q: What does MSL 3 mean for my assembly process? A: MSL 3 (Moisture Sensitivity Level 3) means the components must be mounted within 168 hours (7 days) of opening the vacuum-sealed bag. If exposed longer, you must bake them at specific temperatures to drive out moisture before reflow soldering to prevent internal damage.
Q: What is the typical forward voltage for this Ice Blue LED? A: The forward voltage ranges from 2.8V to 3.4V at 60mA. When designing your driver circuit, ensure it can handle the upper limit (3.4V) to maintain consistent current across the batch.
Q: How should I handle the soldering profile for this component? A: For a lead-free process, peak temperature should not exceed 260°C. Ensure the temperature stays above 217°C for 60 to 120 seconds. For manual soldering, limit contact time to 6 seconds at 260°C.
Q: Are there specific bins for color and intensity? A: Yes. Intensity is graded as H6 (8-10lm) or H7 (10-13lm). Voltage is graded N13-3 through N13-5. Always check the bin code on the packaging label to match your Bill of Materials (BOM).
