📌 Product Overview
The XL-3014UYC-02FJ is a high-performance 3014 SMD LED manufactured by XINGLIGHT. 💡 This component features a yellow light emitter with a water-clear colloid, housed in a compact 3.0x1.4x0.8mm package, making it ideal for space-constrained designs.
Designed for high-density illumination, it supports a maximum forward current of 60mA. 👇 It is engineered for automated SMT production and fully complies with ROHS environmental standards, ensuring suitability for modern, eco-friendly electronic assemblies.
🚀 Typical Applications
Based on its optical characteristics and compact footprint, the XL-3014UYC-02FJ is optimized for the following scenarios:
- Indoor Lighting: Ideal for LED tubes and flexible light strips where consistent color and high intensity are required.
- LCD Backlighting: Provides efficient illumination for display panels due to its 120° viewing angle.
- Commercial Signage: Suitable for advertising boards requiring high reliability and vivid yellow light output.
- Decorative & Automotive: Used in metal plate hard light strips and auxiliary interior automotive lighting.
📊 Key Technical Specifications
The following optical and electrical parameters are measured under standard test conditions (Ta=25°C).
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Test Conditions |
|---|---|---|---|---|---|---|
| Luminous Intensity | Iv | 1150 | - | 1800 | mcd | IF = 60mA |
| Dominant Wavelength | λd | 585 | - | 595 | nm | IF = 60mA |
| Forward Voltage | VF | 1.8 | - | 2.4 | V | IF = 60mA |
| Viewing Angle | 2Ø1/2 | - | 120° | - | deg | IF = 60mA |
| Peak Wavelength | λp | - | 590 | - | nm | IF = 60mA |
| Reverse Current | IR | - | - | ≤ 5 | μA | VR = 5V |
⚠️ Absolute Maximum Ratings & Process Limits
Exceeding these ratings may cause permanent damage. 👇 Design engineers must strictly adhere to these limits to ensure device reliability and prevent thermal runaway during mass production.
| Parameter | Symbol | Max. Value | Unit | Notes |
|---|---|---|---|---|
| Max Power Dissipation | PD | 200 | mW | Ta = 25°C |
| Max Continuous Forward Current | IF | 60 | mA | - |
| Peak Forward Current | IFP | 120 | mA | Pulse ≤ 0.1ms, Duty ≤ 1/10 |
| Max Reverse Voltage | VR | 5 | V | - |
| ESD Ability | ESD | 2000 | V | Human Body Model (HBM) |
| Operating Temperature | TOPR | -40 ~ +85 | °C | - |
| Storage Temperature | TSTR | -40 ~ +85 | °C | - |
| Soldering Temp/Time | TSOL | 260 | °C | ≤ 6 Seconds |
📦 Package, Dimensions & Assembly Notes
- Package Specifications: The component utilizes the standard 3014 footprint.
- Dimensions (L x W x H): 3.0 x 1.4 x 0.8 mm.
- Colloid: Water clear (transparent) for optimal light extraction.
- Soldering Compatibility:
- 🔒 Process: Suitable for both infrared reflow soldering and automated SMT production.
- Moisture Sensitivity: Classified as MSL Level 3. Ensure proper baking and handling per IPC/JEDEC standards to prevent pop-corning during reflow.
- Reflow Profile: Compatible with lead-free processes (Peak temp 255°C to 260°C) and standard leaded profiles.
📈 Sourcing & Supply Considerations
- Grading & Binning: This model is available in specific brightness (F2-F5), voltage (N12-7 to N12-9), and wavelength (HY03-HY06) bins. Specify these codes clearly when ordering to ensure color consistency.
- Supply Chain: Verify authenticity through authorized XINGLIGHT channels.
- Evaluation Samples: Request specific bin samples to test color temperature and intensity in your actual optical housing before bulk procurement.
❓ FAQ
Q: What is the maximum current I can drive the XL-3014UYC-02FJ with continuously? A: The Absolute Maximum Rating for continuous forward current (IF) is 60mA. While it can handle pulses up to 120mA, you must not exceed 60mA DC to avoid thermal degradation.
Q: Is this LED compatible with lead-free soldering processes? A: Yes, the datasheet explicitly lists suitability for infrared reflow soldering. It withstands soldering temperatures up to 260°C for ≤6 seconds, covering standard lead-free requirements.
Q: What does the "Water Colloid" description mean for my design? A: This refers to the transparent encapsulation resin. It typically offers higher light transmission compared to diffused options, resulting in higher luminous intensity (mcd) but a more directional beam.
Q: How should I handle the Moisture Sensitivity Level (MSL)? A: The XL-3014UYC-02FJ is rated MSL 3. If the packaging has been opened, the components should be baked before reflow soldering to remove moisture absorbed from the air, preventing internal damage.
Q: Can I use this component for outdoor applications? A: While the operating temperature range is -40°C to +85°C, this is an SMD component primarily designed for indoor or enclosed commercial lighting (like light strips). For outdoor use, ensure it is housed in an IP-rated fixture with proper waterproofing.
