📌 Product Overview
The XL-304SYGC is a 3.8mm through-hole LED emitting a stable yellow-green light (570nm peak wavelength), optimized for high-reliability applications. Its compact F3 package and low forward voltage (1.8–2.6V @ 20mA) make it ideal for space-constrained designs. Engineered for durability, it supports a wide operating temperature range (-40°C to +85°C) and meets ROHS standards, ensuring compliance in global supply chains.
🔧 Typical Applications
- Automotive Electronics: Dashboard indicators, control panels
- Industrial Controls: Status LEDs, machinery interfaces
- Consumer Electronics: Toys, digital clocks, home appliances
- Medical & Educational Devices: Instrumentation, teaching tools
- Urban Lighting: Decorative, low-power signage
⚙️ Key Technical Specifications
| Parameter | Symbol | Min | Typ | Max | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Luminous Intensity | Iv | 50 | 300 | — | mcd | IF=20mA |
| Dominant Wavelength | λd | 562 | 570 | 575 | nm | IF=20mA |
| Forward Voltage | VF | 1.8 | 2.2 | 2.6 | V | IF=20mA |
| Viewing Angle | 2Ø1/2 | — | 30 | — | deg | IF=20mA |
⚠️ Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Rating | Unit |
|---|---|---|---|
| Consumed Power | Pd | 70 | mW |
| Max Continuous Forward Current | IF | 20 | mA |
| Peak Forward Current | IFp | 80 | mA |
| Operating Temperature | Topr | -20 to +85 | °C |
| Reflow Soldering | Tsol | 240°C, ≤6s | — |
📦 Package, Dimensions & Assembly Notes
- Package Type: F3 through-hole (3.8mm diameter) with white epoxy colloid.
- Dimensions: 3.8×3.0×5.2×28mm (±0.5mm tolerance).
- Assembly: Manual soldering at 300°C (3s); keep lead bend ≥2.0mm from the base to avoid stress.
- Packaging: Moisture-proof, anti-static foil bags (EIA standard).
🚀 Sourcing & Supply Considerations
- Binning Options: Available in brightness (A1–A3), voltage (N12–N13), and wavelength (HYG02–HYG06) grades.
- Reliability: Tested for 1,000hrs under high-temp/humidity (85°C/85% RH) and thermal cycling.
- Supply: RoHS-compliant; verify authenticity through authorized distributors to counter counterfeits.
❓ FAQ
Q: What is the brightness tolerance for the XL-304SYGC?
A: Luminous intensity has a ±10% deviation (e.g., 300mcd ±30mcd).
Q: Is this LED suitable for reflow soldering?
A: Yes, but only for wave/reflow at 240°C for ≤6s; manual soldering must be ≤300°C for 3s.
Q: Can it operate in automotive environments?
A: Its -20°C to +85°C range suits most automotive applications, but verify AEC-Q102 if required.
Q: How are units packaged for mass production?
A: Units are packed in moisture-proof, anti-static bags to prevent ESD damage during storage.
Q: What’s the typical lead time for bulk orders?
A: Lead times vary by region; confirm with XINGLIGHT’s authorized distributors for current stock.
```
