📌 Product Overview
The XL-3210PDC is a surface-mount phototransistor designed for high sensitivity and reliability in compact applications. Its black epoxy colloid enhances optical performance, making it ideal for detecting infrared signals. This component is engineered for seamless integration into automated production lines, specifically targeting environments where precise opto-electric signal conversion is critical, such as in medical equipment and industrial control systems.
🔍 Typical Applications
- Medical equipment
- Infrared remote controllers
- Camera monitoring heads
- Industrial control: counters, thermal imaging, smart meters
- Infrared photoelectric switches
- Wireless communication and signal transmission
- Intelligent cars and robots
⚙️ Key Technical Specifications
| Parameter | Symbol | Min | Typ | Max | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Peak Wavelength | λp | 880 | nm | |||
| Photocurrent (850nm) | IPCE | 300 | 400 | μA | Ee=1mW/cm² | |
| Photocurrent (940nm) | IPCE | 500 | 600 | μA | Ee=1mW/cm² | |
| Current Transfer Ratio | hFE | 200 | 2300 | VCE=5V, IC=2mA | ||
| Rise/Fall Time | tr/tf | 15 | μs | VCE=5V, IC=1mA |
⚠️ Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Max Rating | Unit |
|---|---|---|---|
| Collector-Emitter Voltage | VCEO | 30 | V |
| Emitter-Collector Voltage | VECO | 5 | V |
| Operating Temperature | Topr | -40 ~ +85 | °C |
| IR Reflow (Peak Temp) | Tsol | 260 | °C |
| Manual Soldering (Peak Temp) | Tsol | 300 | °C |
📦 Package, Dimensions & Assembly Notes
The XL-3210PDC is supplied in a compact 1204 (3.2x1.0x2.1mm) SMD package with a black epoxy colloid. It is compliant with EIA standard packaging and features a Moisture Sensitivity Level (MSL) of 3. The device is specifically designed for SMT automated production and is fully compatible with both leaded and lead-free infrared reflow soldering processes, ensuring high manufacturing yield and reliability.
🚀 Sourcing & Supply Considerations
- Authenticity verification is critical due to the component's MSL 3 rating.
- Lead times for production volumes should be confirmed with authorized distributors.
- The IC6-12 photocurrent binning code ensures consistent performance for large-scale deployment.
- Request samples to validate performance against your specific circuit conditions before full-scale production.
❓ FAQ
Q: What is the peak sensitivity wavelength of the XL-3210PDC?
A: The peak sensitivity wavelength (λp) is 880nm.
Q: What is the Moisture Sensitivity Level (MSL) for this component?
A: The XL-3210PDC has an MSL of 3, requiring careful storage and handling before soldering.
Q: What are the recommended soldering profiles?
A: For IR reflow, the peak temperature should not exceed 260°C for 6 seconds. For manual soldering, the limit is 300°C for 3 seconds.
Q: Is the XL-3210PDC suitable for lead-free assembly processes?
A: Yes, it is suitable for both leaded and lead-free infrared reflow soldering processes.
Q: How is the component packaged for shipping?
A: It is packaged according to EIA standard specifications to ensure protection during transit and storage.
