📌 Product Overview
The XL-5730WWC-05 is a Surface Mount Device (SMD) LED designed for general-purpose illumination. 💡 It features a warm white color temperature (2800K–3400K) and utilizes a yellow colloid encapsulation on a 5.7x3.0x0.8mm PLCC frame. 👇 This component is optimized for applications requiring high luminous flux (45-70 lm) within a compact form factor, balancing thermal performance with ease of integration.
⚙️ Typical Applications
Based on its 120° viewing angle and warm white CCT, this model is suitable for:
- Commercial Lighting: Recessed downlights and office lighting modules.
- Linear Lighting: LED light strips and fluorescent tube replacements.
- Signage: Advertising light boxes and illuminated channel letters.
- Backlighting: LCD displays requiring uniform warm white diffusion.
- Decorative Lighting: Flexible strips for ambient accent lighting.
📊 Key Technical Specifications
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Test Conditions |
|---|---|---|---|---|---|---|
| Luminous Flux | Φ | 45 | - | 70 | LM | IF=150mA |
| Color Temp | TC | 2800 | 3000 | 3400 | K | IF=150mA |
| Forward Voltage | VF | 2.8 | - | 3.4 | V | IF=150mA |
| Viewing Angle | 2θ1/2 | - | 120 | - | Deg | IF=150mA |
| CRI | Ra | - | 70 | - | - | IF=150mA |
⚠️ Absolute Maximum Ratings & Process Limits
To ensure reliability during mass production, engineers must strictly adhere to these limits:
- Power Dissipation (Pd): Max 500 mW.
- Forward Current (If): Max 150 mA (Continuous) / 300 mA (Peak).
- Reverse Voltage (Vr): Max 5 V.
- ESD Susceptibility: 2000 V (Human Body Model).
- Thermal: Operating range -40°C to +85°C.
- Soldering: Max 260°C for ≤6 seconds (Manual).
| Parameter | Symbol | Value | Unit |
|---|---|---|---|
| Max Power Dissipation | PD | 500 | mW |
| Max Forward Current | IF | 150 | mA |
| Peak Forward Current | IFP | 300 | mA |
| Operating Temperature | TOPR | -40~+85 | °C |
📦 Package, Dimensions & Assembly Notes
- Dimensions: 5.7mm (L) x 3.0mm (W) x 0.8mm (H).
- Packaging: EIA standard compliant tape and reel.
- Process: Designed for SMT automated assembly and infrared reflow soldering.
- Moisture Sensitivity: MSL Level 3.
- Soldering Guide: Compatible with both lead-free (peak 255°C) and leaded (peak 235°C) reflow profiles. Ensure proper pre-baking if exposed to ambient humidity >60% RH.
🚀 Sourcing & Supply Considerations
- Binning Consistency: Verify voltage (N13) and lumen (J6-J8) bin codes to ensure uniformity in large arrays.
- MSL Compliance: Adhere to MSL Level 3 handling (floor life <168 hours) before reflow to prevent pop-corning.
- Authenticity: Source through authorized channels to guarantee RoHS compliance and lumen maintenance specs.
- Evaluation: Request samples with specific bin codes for prototyping to validate thermal management in the final housing.
❓ FAQ
Q: What is the forward voltage range for this LED?
A: The forward voltage (VF) ranges from 2.8V to 3.4V at a typical forward current of 150mA. Designers should account for this variance in driver calculations.
Q: Is this component suitable for high-density LED strips?
A: Yes, with a footprint of 5.7x3.0mm and 0.8mm height, it is ideal for standard 5730 strip layouts, provided the PCB traces handle 150mA current density.
Q: What are the storage requirements to prevent moisture damage?
A: The MSL is Level 3. If the moisture barrier bag is open, components must be used within 168 hours or baked according to J-STD-033 standards before reflow soldering.
Q: Can this LED be used in outdoor lighting fixtures?
A: While the operating temperature is rated up to 85°C, the IP rating depends on the final fixture design. The LED itself is not waterproof but is suitable for internal fixtures within an outdoor-rated housing.
Q: What is the typical Color Rendering Index (CRI)?
A: The datasheet specifies a typical CRI (Ra) of 70, making it suitable for general commercial and decorative lighting where high color fidelity is not critical.
