📌 Product Overview
The XL-A324SURUGC is a compact F3-packaged dual-color (red/green) LED featuring high brightness and a transparent epoxy body. Designed for low-voltage DC operation (1.8–3.4V), it targets applications requiring reliable color indication or backlighting. Its RoHS-compliant construction and MSL 2 rating ensure environmental and manufacturing compatibility. The device prioritizes longevity and energy efficiency, making it suitable for both consumer and automotive-grade designs.
🔍 Typical Applications
- Backlight modules for displays and indicators
- Automotive interior lighting and signal systems
- Smart home control panels and status indicators
- General-purpose lighting with dual-color output
⚙️ Key Technical Specifications
| Parameter | Red (Min/Max) | Green (Min/Max) | Unit | Test Condition |
|---|---|---|---|---|
| Luminous Intensity | 400/700 | 2100/4000 | mcd | IF=20mA |
| Dominant Wavelength | 630/640 | 520/530 | nm | IF=20mA |
| Forward Voltage | 1.8/2.4 | 2.8/3.4 | V | IF=20mA |
| Viewing Angle | 30° | 30° | deg | IF=20mA |
⚠️ Absolute Maximum Ratings & Process Limits
| Parameter | Red/Green | Unit |
|---|---|---|
| Max Continuous Forward Current | 20 | mA |
| Peak Forward Current | 80 | mA |
| Power Dissipation | 50/70 | mW |
| Operating Temperature | -20 to +85 | °C |
| Reflow Soldering | 240°C, ≤6s | - |
| Manual Soldering | 300°C, 3s | - |
📏 Package, Dimensions & Assembly Notes
- Package Type: F3 (3.8x3.0x5.2mm) with common cathode
- Soldering Notes: Lead-free compatible; solder joint must be ≥2.0mm from epoxy body
- Moisture Sensitivity: MSL 2 (storage conditions per JEDEC J-STD-020)
- Handling: EIA standard packaging for automated assembly
🚀 Sourcing & Supply Considerations
- Binning Options: Available in brightness (A5-B6), voltage (N12-7-N13-5), and wavelength (HG03-HR05) grades
- Sample Support: Contact XINGLIGHT for custom binning requests or volume quotations
- Authenticity: Verify distributors for genuine components to counter counterfeits
❓ FAQ
Q: What is the typical lifespan of the XL-A324SURUGC?
A: Tested for 1000 hours at 25°C with 0 failures per 22 samples, ensuring long-term reliability.
Q: Are there specific binning codes for color consistency?
A: Yes, wavelength bins (e.g., HR04 for red: 630–635nm) and brightness bins (e.g., B5 for green: 3000–3500 mcd) are available.
Q: Can this LED withstand automotive temperature cycles?
A: Yes, it passes cold/hot cycling (-40°C to +105°C) and high-temperature storage (85°C) tests.
Q: What are the soldering restrictions?
A: Reflow must not exceed 240°C for 6s; manual soldering is limited to 300°C for 3s, with a 2.0mm clearance from the epoxy.
```
