XINGLIGHT XL-3030WWC-1W-6V High Brightness White LED Specifications
Product Overview
XL-3030WWC-1W-6V is a 1W high brightness white SMD LED from XINGLIGHT (成兴光), designed for indoor and commercial lighting applications. The 3.0×3.0×0.6mm compact package delivers 100-130lm luminous intensity with a warm-to-cool white color temperature range of 2800-3200K.
Electrical Specifications
Absolute Maximum Ratings (Ta=25°C)
| Parameter | Symbol | Value | Unit |
|---|---|---|---|
| Maximum Power Dissipation | Pd | 1000 | mW |
| Forward Current | IF | 150 | mA |
| Reverse Voltage | VR | 10 | V |
| Operating Temperature Range | TOPR | -40 ~ +85 | °C |
| Storage Temperature Range | TSTR | -40 ~ +85 | °C |
| Peak Pulsing Current | IFP | 500 | mA |
| Soldering Temperature | TSOL | 260 | °C (≤6s) |
| Electrostatic Discharge (ESD) | ESD | 2000 | V |
Optical Characteristics (IF=1mA, 50mA, 150mA)
| Parameter | IF=1mA | IF=50mA | IF=150mA | Unit |
|---|---|---|---|---|
| Forward Voltage (VF) | 6.0 | -- | 6.0 -- 6.4 | V |
| Luminous Intensity (Iv) | -- | -- | 100 -- 130 | lm |
| Color Temperature (TC) | 2800 | 2800 | 2800 -- 3200 | K |
| Half Light Angle (2θ1/2) | -- | 120 | -- | ° |
| Reverse Current (Ir) | -- | -- | -- | ≤5 |
Brightness Grading (IF=150mA)
| Code | Luminous Intensity | Unit |
|---|---|---|
| K3 | 100 | lm |
| K4 | 110 | lm |
| K5 | 120 | lm |
| (Max) | 130 | lm |
Forward Voltage Grading (IF=150mA)
| Code | VF Range | Unit |
|---|---|---|
| N15-1 | 6.0-6.2 | V |
| N15-2 | 6.2-6.4 | V |
Color Temperature Grading (IF=150mA)
| Code | TC Range | Unit |
|---|---|---|
| WW2 | 2800-3000 | K |
| WW4 | 3000-3200 | K |
Key Features
- High Brightness: 100-130lm luminous intensity at 150mA drive current
- Flexible Color Temperature: 2800-3200K range from warm to cool white
- Compact Package: 3.0×3.0×0.6mm dimensions for space-efficient designs
- High ESD Protection: 2000V antistatic capability for enhanced reliability
- Wide Operating Range: -40°C to +85°C for diverse environments
- Pulse Capability: 500mA peak current for short-duration applications
- RoHS Compliant: Meets environmental protection requirements
Applications
- Indoor Lighting: Fluorescent tubes, light strips, down lights
- Commercial: Lighting displays, advertising words, light boxes
- LCD Backlight: Backlight source for liquid crystal displays
- Decorative: Flexible light strips, ambient lighting
Selection Guidance
When selecting XL-3030WWC-1W-6V for your design:
Brightness Requirements: Choose K3/K4/K5 grading based on required luminous intensity (100-130lm at 150mA)
Voltage Matching: Select appropriate VF grading (N15-1/2) to match your circuit design (6.0-6.4V range)
Color Temperature: Pick WW2/WW4 codes for desired white tone (2800-3200K range)
Space Constraints: Verify 3.0×3.0×0.6mm footprint compatibility with your PCB layout
Pulse Applications: Peak current up to 500mA for short-duration lighting effects
Summary
XL-3030WWC-1W-6V is a reliable high brightness white SMD LED suitable for indoor and commercial lighting applications requiring consistent white illumination with flexible color temperature options.
