• 3.4 × 3.3 × 1.9 mm compact package size for space-constrained designs
• 23-39 lm luminous intensity at 615-630 nm dominant wavelength
• 150 mA continuous forward current with 300 mA pulse capability
• Operating temperature range: -40°C to +85°C for automotive applications
🎯 Product Overview
XINGLIGHT XL-3433SURC-05 is a surface-mount red LED designed for automotive and general lighting applications. The 3.4 × 3.3 × 1.9 mm outline dimensions provide compact footprint for high-density PCB layouts while maintaining robust thermal performance through infrared reflow soldering process.
The component features colorless transparent encapsulation with red emission at 615-630 nm dominant wavelength, making it suitable for applications requiring standard red lighting characteristics, particularly automotive brake and taillight systems.
📊 Electrical Specifications
Absolute Maximum Ratings (Ta=25°C):
- Power Dissipation: 500 mW
- Continuous Forward Current: 150 mA
- Peak Forward Current: 300 mA (pulse width ≤ 0.1ms, duty cycle ≤ 1/10)
- Reverse Voltage: 5 V
- ESD Resistance: 2000 V
- Operating Temperature: -40°C to +85°C
- Storage Temperature: -40°C to +85°C
- Soldering Temperature/Time: 260°C ≤ 6S
Optical Characteristics (IF=15mA):
- Luminous Intensity: 23-39 lm
- Dominant Wavelength: 615-630 nm
- Peak Wavelength: 625 nm
- Forward Voltage: 1.8-2.4 V
- Viewing Angle: 120°
- Half Wave Width: 20 nm
Brightness Grading (IF=150mA):
- J2: 23-27 lm
- J3: 27-33 lm
- J4: 33-39 lm
Voltage Grading (IF=150mA):
- N12-7: 1.8-2.0 V
- N12-8: 2.0-2.2 V
- N12-9: 2.2-2.4 V
Wavelength Grading (IF=150mA):
- HR01: 615-620 nm
- HR02: 620-625 nm
- HR03: 625-630 nm
📋 Applications
XL-3433SURC-05 is designed for applications requiring red emission with compact package size:
Automotive:
- Car taillights and brake lights
- Turn signal indicators
- Interior lighting and dashboard illumination
Commercial Lighting:
- Advertising light boxes and signage
- Commercial display backlighting
- Retail shelf lighting
General Lighting:
- Indoor lighting fixtures
- Decorative flexible light strips
- LCD backlight applications
🔍 Design Considerations
The component complies with ROHS environmental requirements and uses EIA standard packaging suitable for SMT automated production. Moisture sensitivity level (MSL) is rated at 3, requiring appropriate handling procedures before soldering.
Designers should consider 120° viewing angle for uniform light distribution and account for forward voltage variation (1.8-2.4 V) when designing drive circuits. The wide operating temperature range supports automotive-grade applications where environmental conditions fluctuate.
⚡ Selection Guidance
For applications requiring maximum brightness, specify J4 brightness grade (33-39 lm) with N12-7 voltage bin (1.8-2.0 V) for optimal efficiency. Standard automotive taillight applications typically utilize J3 or J4 grades with HR02 or HR03 wavelength bins for consistent red color perception across vehicle fleet.
The 2000 V ESD resistance provides robust protection against electrostatic discharge during handling and assembly, reducing failure rates in manufacturing environments.
