📌 Product Overview
The XL-1515RGBC-WS2812B is an intelligent surface-mount LED component designed for high-density full-color lighting. 💡 It integrates a WS2812B control IC directly within the 1.5mm x 1.5mm x 0.65mm package, enabling single-line data transmission and individual pixel addressing without complex external drivers.
This component is specifically engineered for applications requiring space-constrained designs with complex color mixing. ⚡ By utilizing an optimized 5mA constant current drive per channel and internal signal reshaping, it ensures consistent brightness and color uniformity across long cascades, making it ideal for luminous characters and dynamic guardrail tubes.
🎯 Typical Applications
- LED Full-Color Modules & Luminous Characters: Suited for channel letters and advertising signs requiring high refresh rates and uniform color blending.
- Magic Color Light Strips: Designed for flexible and rigid strip lighting where minimal PCB footprint (1515 size) is critical for tight installation spaces.
- Irregular Screen & Pixel Displays: Supports high-density pixel mapping for creative LED screens and shaped displays due to its 120° viewing angle.
- Electronic Indicators: Implemented in consumer electronics and appliances for dynamic running light effects and status indication.
- Scene & Ambient Lighting: Utilized in architectural lighting and mood settings requiring 256-level grayscale adjustment for smooth color transitions.
⚙️ Key Technical Specifications
| Parameter | Conditions | Min | Typ | Max | Unit |
|---|---|---|---|---|---|
| Supply Voltage (VDD) | Operating | 3.5 | 5.0 | 5.5 | V |
| Drive Current (R/G/B) | Constant Current Mode | - | 5.0 | - | mA |
| Luminous Intensity (IV) | Green (Typ) | 200 | - | 400 | mcd |
| Data Transfer Speed | fDATA | - | 800 | - | kHz |
| PWM Frequency | Output Port | - | 1.5 | - | kHz |
| Grayscale | Depth | - | 256 | - | Levels |
| Viewing Angle | 2θ1/2 | - | 120 | - | Deg |
💡 The internal IC features strong data shaping capabilities, allowing for stable signal transmission even when driving over 1024 pixels at a 30fps refresh rate.
⚠️ Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Rating | Unit |
|---|---|---|---|
| Supply Voltage | VDD | 3.5 - 5.5 | V |
| Logic Input Voltage | VDI | -0.5 ~ VDD+0.5 | V |
| Output Port Voltage | VOUT | 13 | V |
| Operating Temperature | Topr | -40 ~ +85 | °C |
| Storage Temperature | Tstg | -40 ~ +85 | °C |
| Reflow Soldering | Tsol | 260°C for 6s | °C/s |
| ESD Sensitivity | ESD (HBM) | 2000 | V |
⚠️ Critical Design Note: The component has a Moisture Sensitivity Level (MSL) of 5. Proper baking and handling procedures are mandatory prior to infrared reflow soldering to prevent popcorn cracking or delamination.
📦 Package, Dimensions & Assembly Notes
- Package Type: 1515 SMD (1.5mm x 1.5mm).
- Dimensions: Length: 1.5mm, Width: 1.5mm, Height: 0.65mm.
- Colloid: Transparent water-clear gel for optimal light transmission.
- Assembly: Designed for fully automated SMT production lines.
- Soldering: Compatible with standard infrared reflow processes; temperature profiles must not exceed 260°C for more than 6 seconds.
🔒 Due to the low Z-height (0.65mm), this component is ideal for ultra-thin flexible light strips where clearance is minimal. Ensure stencil design accounts for the small footprint to prevent solder bridging.
📈 Sourcing & Supply Considerations
- Supply Chain: Verify packaging specifications comply with EIA standards to ensure compatibility with automated pick-and-place machinery.
- MSL Management: Since the MSL is Level 5, confirm that suppliers provide vacuum-sealed packaging with appropriate desiccant to prevent moisture absorption during transit.
- Quality Consistency: For large-scale lighting projects, request binning data on wavelength and intensity to ensure color uniformity across different production batches.
❓ FAQ
Q: What is the maximum number of LEDs that can be cascaded in a single string?
A: While theoretically infinite due to the signal reshaping technology, the datasheet specifies stable performance for at least 1024 points when refreshing at 30fps (800Kbps).
Q: Does this LED require external resistors for current control?
A: No. The XL-1515RGBC-WS2812B integrates an internal constant current IC set to 5mA per channel, eliminating the need for external current-limiting resistors on the PCB.
Q: What are the power supply requirements for a large installation?
A: The supply voltage (VDD) must be regulated between 3.5V and 5.5V. A 5V supply is typical. Ensure the power supply can handle the aggregate current (max ~15mA per LED when white).
Q: Is this component suitable for outdoor applications?
A: While the LED itself operates from -40°C to +85°C, the packaging uses transparent colloid. For outdoor use, additional waterproofing measures (silicone encapsulation or IP-rated tubing) are recommended to protect the SMD connections from humidity.
