📌 Product Overview
The XL-1608UGC-06 is a miniature 0603 (1.6x0.8x0.6mm) surface-mount LED emitting a bright green light. Designed for high-density applications, its primary focus is on reliability and integration into automated SMT production lines. This component is engineered for applications where space is critical, such as in portable medical devices, automotive indicator lights, and compact industrial control panels.
💡 Typical Applications
- Medical Equipment: Endoscopes, oximeters
- Automotive Electronics: Backlight key lights, indicator lights
- Industrial Products: Electronic instrument panels, industrial equipment
- Smart Home: White appliances, nixie tube LEDs
- Communication Products: Mobile phone button lamps, routers, TV boxes
🔑 Key Technical Specifications
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Luminous Intensity | Iv | 450 | / | 1000 | mcd | IF=20mA |
| Dominant Wavelength | λd | 520 | / | 535 | nm | IF=20mA |
| Forward Voltage | VF | 2.6 | / | 3.4 | V | IF=20mA |
| Viewing Angle | 2Ø1/2 | / | 120° | / | deg | IF=20mA |
⚠️ Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Value | Unit |
|---|---|---|---|
| Max Power Dissipation | PD | 70 | mW |
| Max Continuous Forward Current | IF | 20 | mA |
| Peak Forward Current | IFP | 80 | mA |
| Max Reverse Voltage | VR | 5 | V |
| Operating Temperature | TOPR | -40 ~ +85 | °C |
| Soldering Temperature/Time | TSOL | 260℃ / ≤6s | / |
📏 Package, Dimensions & Assembly Notes
The XL-1608UGC-06 utilizes a standard 0603 (1608 metric) package with dimensions of 1.6x0.8x0.6mm. It is packaged according to EIA standards and is suitable for automated SMT placement. The device has a Moisture Sensitivity Level (MSL) of 3, requiring standard baking and handling procedures before reflow soldering to prevent popcorning.
🚀 Sourcing & Supply Considerations
- Verify authenticity through authorized XINGLIGHT distributors to avoid counterfeit components.
- Lead times and minimum order quantities (MOQs) are subject to availability and should be confirmed with suppliers.
- Request samples for initial design validation and thermal testing in the target application.
- Confirm RoHS compliance and environmental suitability for your target market.
❓ FAQ
Q: What are the brightness and voltage binning options for the XL-1608UGC-06? A: The LED is available in multiple brightness bins (E3-E9, 450-1000 mcd) and voltage bins (M18-8 to M19-5, 2.6-3.4V) to allow for precise current regulation and consistent visual output in production.
Q: Is the XL-1608UGC-06 suitable for lead-free soldering processes? A: Yes, the device is compatible with standard lead-free reflow profiles. The peak temperature must not exceed 235°C, and the time above liquidus (TAL) should be 10-15 seconds, adhering to J-STD-020C guidelines.
Q: What is the ESD protection rating for this LED? A: The XL-1608UGC-06 has an anti-static ability rating of 2000V, providing a good level of protection against electrostatic discharge during handling and assembly.
Q: Can this LED be used in high-temperature automotive environments? A: The operating temperature range is -40°C to +85°C, which is suitable for many automotive applications. However, specific validation for the automotive environment (e.g., AEC-Q101) should be performed if required.
