📌 Product Overview
The XL-1608UWC-06 is a surface-mount LED from XINGLIGHT, designed for high-density circuit assembly. Its ultra-compact dimensions of 1.6x0.8x0.6mm make it suitable for applications where board space is at a premium. This LED is engineered for reliability and performance in demanding environments, focusing on low power consumption and a wide 120° viewing angle to ensure clear visibility in various lighting conditions.
🚀 Typical Applications
- Medical equipment: Endoscopes, oximeters
- Automotive electronics: Backlight key lights, indicator lights
- Industrial products: Electronic instrument panels, industrial equipment
- Smart home: White appliances, nixie tube LEDs
- Communication products: Mobile phone button lamps, routers
🔑 Key Technical Specifications
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Luminous Intensity | IV | 360 | - | 1000 | mcd | IF=20mA |
| Forward Voltage | VF | 2.6 | - | 3.4 | V | IF=20mA |
| Viewing Angle | 2θ1/2 | - | 120° | - | Deg | IF=20mA |
| Color Temperature | TC | 10000 | - | 25000 | K | IF=20mA |
⚠️ Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Value | Unit |
|---|---|---|---|
| Max Continuous Forward Current | IF | 20 | mA |
| Max Power Dissipation | PD | 75 | mW |
| Operating Temperature | TOPR | -40 to +85 | °C |
| ESD Protection | ESD | 2000 | V |
| Soldering Temp/Time | TSOL | 260°C / ≤6s | - |
📦 Package, Dimensions & Assembly Notes
The XL-1608UWC-06 utilizes a standard SMD package with a 1.6x0.8x0.6mm outline, designed for automated SMT assembly. It features a yellow mist epoxy colloid and complies with EIA standard packaging. Moisture sensitivity is rated at MSL 3. For assembly, adhere to standard reflow profiles, with a peak temperature not exceeding 260°C for a duration of 6 seconds or less.
🛒 Sourcing & Supply Considerations
- Ensure samples are requested to verify brightness and voltage binning for your application.
- Confirm lead-time and minimum order quantity for mass production planning.
- Verify channel authenticity to avoid counterfeit components that may fail reliability testing.
❓ FAQ
Q: What are the brightness and voltage binning options for the XL-1608UWC-06? A: Brightness is graded from E1 (350-400 mcd) to E9 (900-1000 mcd), with a ±10% tolerance. Voltage is graded in 0.1V increments from 2.6V to 3.4V.
Q: Is this LED suitable for high-temperature reflow soldering? A: Yes, it can withstand a peak soldering temperature of 260°C for a maximum of 6 seconds, making it compatible with standard SMT processes.
Q: What is the moisture sensitivity level, and how should it be handled? A: The MSL is 3. Components must be baked and handled according to IPC/JEDEC standards before soldering to prevent moisture-induced damage.
Q: Can this LED be used in automotive applications? A: While its specifications are suitable for automotive indicator lights, please verify if it meets the specific AEC-Q102 grade required for your application.
Q: What is the typical color bin for this white LED? A: The main color bin for the standard white version is C1, with product code CW5-21.
