📌 Product Overview
The XL-1608UYC-06FJ is a compact surface-mount LED from XINGLIGHT, featuring a 1.6×0.8×0.6mm footprint and yellow luminous output. Designed for precision applications, it supports SMT automation and offers low power consumption with a wide 120° viewing angle. Ideal for space-constrained environments requiring reliable, high-intensity illumination.
🔍 Typical Applications
- Medical equipment: Endoscopes, oximeters
- Automotive electronics: Backlight keypads, indicator lights
- Industrial products: Instrument panels, control devices
- Smart home: White appliances, nixie tube displays
- Communication: Mobile phone buttons, routers, set-top boxes
⚙️ Key Technical Specifications
| Parameter | Symbol | Min | Typ | Max | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Luminous Intensity | Iv | 240 | - | 600 | mcd | IF=20mA |
| Dominant Wavelength | λd | 585 | - | 595 | nm | IF=20mA |
| Forward Voltage | VF | 1.9 | - | 2.3 | V | IF=20mA |
| Viewing Angle | 2θ1/2 | - | 120° | - | deg | IF=20mA |
⚠️ Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Value | Unit |
|---|---|---|---|
| Max Power Dissipation | PD | 60 | mW |
| Max Continuous Forward Current | IF | 30 | mA |
| Peak Forward Current | IFP | 80 | mA |
| Operating Temperature | TOPR | -40 ~ +85 | °C |
| Soldering Temp/Time | TSOL | 260°C ≤ 6s | - |
📏 Package, Dimensions & Assembly Notes
- Ultra-compact SMD package (1.6×0.8×0.6mm)
- Moisture Sensitivity Level (MSL): 3
- Compatible with EIA standard packaging
- Suitable for IR reflow soldering (lead-free/leaded profiles)
- Water-clear epoxy colloid for enhanced light transmission
🚀 Sourcing & Supply Considerations
- ROHS-compliant manufacturing
- Brightness/voltage/wavelength binning available
- ESD protection (2000V) for reliability
- Supply chain support for mass production
❓ FAQ
Q: What is the brightness grading for this LED?
A: Brightness is graded from D7 (240 mcd) to E5 (600 mcd) with ±10% tolerance.
Q: Is it suitable for automotive applications?
A: Yes, its wide viewing angle and low power make it ideal for backlight indicators in automotive electronics.
Q: What is the recommended soldering profile?
A: Follow J-STD-020C for lead-free (peak 255°C) or MIL-STD-750D for leaded processes (peak 235°C).
Q: Can it withstand high-temperature storage?
A: Yes, rated for -40°C to +85°C operating/storage and tested at 85°C/90% RH for 240 hours.
Q: What packaging options are available?
A: EIA standard tape-and-reel packaging for automated SMT assembly.
Q: How does its wavelength compare to competitors?
A: Dominant wavelength ranges from 585–595 nm (±1nm tolerance), suitable for consistent yellow output.
