📌 Product Overview
The XL-1608VRC-06 is a compact surface-mount LED (1.6x0.8x0.6mm) designed for high-precision applications. Its red emission (615-630nm) and wide 120° viewing angle make it ideal for space-constrained electronics. Key features include low power consumption, ROHS compliance, and SMT compatibility, ensuring reliability in demanding environments like medical devices and automotive systems.
🔍 Typical Applications
- Medical equipment: Endoscopes, oximeters
- Automotive electronics: Backlight keypads, indicator lights
- Industrial products: Instrument panels, control systems
- Smart home: White appliances, numeric displays
- Communication devices: Mobile phone keypads, routers
⚙️ Key Technical Specifications
| Parameter | Symbol | Min | Typ | Max | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Luminous Intensity | Iv | 120 | - | 300 | mcd | IF=20mA |
| Dominant Wavelength | λd | 615 | - | 630 | nm | IF=20mA |
| Forward Voltage | VF | 2.7 | - | 3.4 | V | IF=20mA |
| Viewing Angle | 2Ø1/2 | - | 120 | - | deg | IF=20mA |
⚠️ Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Value | Unit |
|---|---|---|---|
| Max Power Dissipation | PD | 70 | mW |
| Max Continuous Forward Current | IF | 20 | mA |
| Peak Forward Current | IFP | 80 | mA |
| Operating Temperature | TOPR | -40 ~ +85 | °C |
| ESD Rating | ESD | 2000 | V |
📦 Package, Dimensions & Assembly Notes
- Package: 1608 (0603) SMD outline (1.6x0.8x0.6mm)
- Moisture Sensitivity Level (MSL): 3 (requires baking before reflow)
- Soldering: IR reflow (max 260°C, ≤6s) or wave soldering (235°C, ≤2s)
- Compliance: ROHS-compliant, EIA-standard packaging
🚀 Sourcing & Supply Considerations
- Brightness/voltage/wavelength binning available (e.g., D3-D8, M18-9, HR01-HR03)
- MSL-3 requires strict moisture control during storage and handling
- Lead-free and leaded soldering profiles supported per J-STD-020C
- Verify authenticity through authorized distributors to avoid counterfeits
❓ FAQ
Q: What is the brightness tolerance?
A: ±10% (e.g., D3 bin: 120-150 mcd at IF=20mA).
Q: Is this LED suitable for high-temperature automotive use?
A: Yes, operating range is -40°C to +85°C, meeting automotive requirements.
Q: How should I handle moisture sensitivity?
A: MSL-3; bake at 125°C for 24 hours if exposed to >72 hours at >30% RH.
Q: Can it withstand IR reflow soldering?
A: Yes, with lead-free (255°C, 10s) or leaded (260°C, 6s) profiles.
Q: What’s the typical lead time for mass production?
A: 8-12 weeks for standard orders; confirm with XINGLIGHT for urgent needs.
Q: Are there drop-in alternatives?
A: Verify mechanical/electrical compatibility; direct cross-references may vary by vendor.
