📌 Product Overview
The XINGLIGHT XL-3216PDC is a surface-mount phototransistor engineered for efficient infrared light detection. Its compact 3.2 x 1.6 x 0.8mm footprint and black epoxy colloid are optimized for high-density circuit assembly. Designed for SMT automation, it provides reliable optical-to-electrical signal conversion, making it a critical component for modern, space-constrained electronic designs requiring precise sensing capabilities.
🔍 Typical Applications
- Smart home appliance iris recognition systems
- Infrared luminescent micro light barriers
- Photoelectric switches and induction switches
- Smoke detectors
- Infrared sensors
- Floppy disk drivers
📊 Key Technical Specifications
| Parameter | Symbol | Min | Typ | Max | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Peak Wavelength | λp | 880 | nm | |||
| Collector Dark Current | I_CEO | 30 | nA | V_CE=20V, Ee=0 | ||
| Current Gain | h_FE | 200 | 2300 | V_CE=5V, I_C=2mA | ||
| Photocurrent (850nm) | I_PCE | 300 | 400 | μA | V_CE=5V, Ee=1mW/cm² | |
| Photocurrent (940nm) | I_PCE | 500 | 600 | μA | V_CE=5V, Ee=1mW/cm² | |
| Rise Time | T_r | 15 | μs | R_L=1kΩ |
⚠️ Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Max Rating | Unit | Condition |
|---|---|---|---|---|
| Collector-Emitter Voltage | V_CEO | 30 | V | |
| Emitter-Collector Voltage | V_ECO | 5 | V | |
| Operating Temp. | T_opr | -40 to +85 | °C | |
| Reflow Solder | T_sol | 260 | °C | 6s max |
📦 Package, Dimensions & Assembly Notes
The XL-3216PDC is packaged in a compact SMD outline measuring 3.2 x 1.6 x 0.8mm. It is compliant with ROHS environmental standards and features a Moisture Sensitivity Level (MSL) of 3-4. It is suitable for infrared reflow soldering processes, ensuring compatibility with standard SMT manufacturing lines. EIA standard packaging is used for reliable handling and placement.
🚀 Sourcing & Supply Considerations
- Sample Support: Contact XINGLIGHT for engineering samples to validate performance.
- Mass Production: Lead times are subject to order volume and current market conditions.
- Alternative Evaluation: Direct cross-referencing is recommended due to binning variations.
- Channel Verification: Ensure procurement from authorized distributors to guarantee authenticity.
❓ FAQ
Q: What is the peak sensitivity wavelength of the XL-3216PDC?
A: The typical peak sensitivity wavelength (λp) is 880nm.
Q: What is the Moisture Sensitivity Level (MSL) for this component?
A: The MSL is 3-4, indicating it requires specific handling and baking before SMT assembly to prevent damage.
Q: What are the recommended soldering conditions?
A: For reflow soldering, the peak temperature should not exceed 260°C for a maximum of 6 seconds. Manual soldering should be done at 300°C for a maximum of 3 seconds.
Q: Is the XL-3216PDC suitable for lead-free soldering processes?
A: Yes, it is suitable for both standard and lead-free (Pb-free) infrared reflow soldering processes, adhering to industry standards like J-STD-020C.
Q: What are the typical applications for this phototransistor?
A: It is commonly used in applications like iris recognition, photoelectric switches, smoke detectors, and infrared sensors where compact, reliable light detection is required.
