📌 Product Overview
The XL-TD3216PDC is a compact, surface-mount phototransistor manufactured by XINGLIGHT. Housed in a 3.2x1.6mm black epoxy package, this component is engineered for seamless integration into automated SMT assembly lines. Its design prioritizes reliability in demanding environments, making it suitable for applications requiring precise infrared detection. The device is compliant with ROHS standards and features a moisture sensitivity level (MSL) of 3, ensuring compatibility with standard manufacturing processes.
💡 Typical Applications
- Smart Home & Security: Iris recognition systems, induction switches.
- Industrial Automation: Photoelectric switches, infrared sensors, micro light barriers.
- Consumer Electronics: Smoke detectors, floppy disk drives.
- General Sensing: Any application requiring reliable infrared light-to-current conversion.
🔑 Key Technical Specifications
| Parameter | Symbol | Min | Typ | Max | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Peak Wavelength | λp | - | 880 | - | nm | - |
| Collector Dark Current | ICEO | - | - | 30 | nA | VCE=20V |
| Current Transfer Ratio | hFE | 200 | - | 2300 | - | VCE=5V, IC=2mA |
| Rise/Fall Time | tr/tf | - | 15 | - | µs | RL=1kΩ |
⚡ Absolute Maximum Ratings & Process Limits
Electrical and thermal parameters that must not be exceeded under any operating conditions. Adherence to these limits is critical for device longevity and preventing permanent damage. The wide operating temperature range of -40°C to +85°C ensures suitability for diverse environments.
| Parameter | Symbol | Max Rating | Unit |
|---|---|---|---|
| Collector-Emitter Voltage | VCEO | 30 | V |
| Emitter-Collector Voltage | VECO | 5 | V |
| Operating Temperature | Topr | -40 to +85 | °C |
| IR Reflow Soldering | Tsol | 260°C for 6s | - |
📏 Package, Dimensions & Assembly Notes
The XL-TD3216PDC is packaged in a standard 1206 (3.2x1.6mm) SMD format with a black epoxy colloid. It is specifically designed for automated SMT placement and is compatible with both leaded and lead-free infrared reflow soldering processes. The recommended solder profile includes a peak temperature of 235°C (leaded) or 255°C (lead-free) with a dwell time of 10-15 seconds or 5-10 seconds, respectively.
🚀 Sourcing & Supply Considerations
- Supply Chain: This component is available in standard EIA-compliant tape and reel packaging for automated assembly.
- Consistency: The device is graded for photo current (IC23-25: 4-6mA) to ensure performance consistency in volume production.
- Verification: For authentic components, please verify through official XINGLIGHT distributors or directly with the manufacturer to avoid counterfeit risks.
❓ FAQ
Q: What is the moisture sensitivity level (MSL) for the XL-TD3216PDC?
A: The MSL is 3, requiring standard baking and handling procedures before SMT assembly to prevent moisture-induced damage.
Q: What is the peak sensitivity wavelength of this phototransistor?
A: The peak sensitivity wavelength (λp) is 880nm, with a spectral bandwidth ranging from 700nm to 1100nm.
Q: Is the XL-TD3216PDC suitable for lead-free soldering processes?
A: Yes, it is compatible with both leaded and lead-free infrared reflow soldering processes, with peak temperatures up to 255°C.
Q: How does the photo current grading work for this part?
A: The phototransistor is graded into codes (e.g., IC23-25), ensuring the photo current (IPCE) falls within a specified range (4-6mA @ Ee=1mW/cm², λp=940nm, VCE=5V) for predictable performance.
Q: What is the maximum collector-emitter voltage rating?
A: The absolute maximum rating for the collector-emitter voltage (VCEO) is 30V. Exceeding this value will result in device failure.
