📌 Product Overview
The XL-3433UYC-02 is a high-performance Yellow SMD LED from XINGLIGHT, 📦 packaged in a compact 3.4x3.3x1.9mm footprint with a water-clear lens. It is specifically engineered for applications requiring strong luminous intensity and robust thermal management, such as automotive exterior lighting and commercial signage. ✨ While the nominal specifications are standard, the real design focus lies in managing the 60mA forward current to maintain color consistency within the 585-595nm wavelength range.
🎯 Typical Applications
Based on its optical characteristics and robust thermal range (-40°C to +85°C), this component is ideal for:
- Automotive Lighting: Tail lights and indicator lights requiring high reliability.
- Commercial Display: Advertising light boxes and backlighting for LCDs.
- Interior & Decor: Flexible light strips and interior ambient lighting.
- Industrial Indication: Status indicators where high visibility is critical.
📊 Key Technical Specifications
💡 The following optical and electrical parameters are measured at standard conditions (Ta=25°C, IF=60mA):
| Parameter | Symbol | Min. | Typ. | Max. | Unit |
|---|---|---|---|---|---|
| Luminous Intensity | Φ | 10 | - | 20 | LM |
| Dominant Wavelength | λd | 585 | - | 595 | nm |
| Forward Voltage | VF | 1.8 | - | 2.4 | V |
| Viewing Angle | 2Ø1/2 | - | 120° | - | deg |
| Reverse Current | IR | - | - | ≤5 | μA |
⚠️ Absolute Maximum Ratings & Process Limits
🔒 Exceeding these limits may cause permanent damage. Design margins must account for the 60mA continuous current ceiling.
| Parameter | Symbol | Max. Value | Unit | Notes |
|---|---|---|---|---|
| Max Power Dissipation | PD | 200 | mW | - |
| Max Forward Current | IF | 60 | mA | Continuous DC |
| Peak Forward Current | IFP | 120 | mA | Pulse ≤0.1ms |
| Max Reverse Voltage | VR | 5 | V | - |
| ESD Ability | ESD | 2000 | V | Human Body Model |
| Operating Temp. | TOPR | -40 ~ +85 | °C | - |
📦 Package, Dimensions & Assembly Notes
The component utilizes a 3433 metric surface-mount package (3.4mm x 3.3mm x 1.9mm). 👇 Key assembly and reliability considerations include:
- Soldering: Compatible with Infrared Reflow soldering.
- Moisture Sensitivity: Classified as MSL Level 3.
- Thermal Profile:
- Lead-free: Peak 255°C (max 6°C/sec ramp).
- Lead process: Peak 235°C.
- Packaging: EIA standard compliant for automated SMT production.
🚀 Sourcing & Supply Considerations
When integrating the XL-3433UYC-02 into mass production, verify the following supply chain factors:
- Bin Selection: Confirm specific Brightness (H7-H9) and Voltage (N12-7 to N12-9) grades to match driver circuits.
- Authenticity: Source exclusively through XINGLIGHT authorized channels to ensure ROHS compliance.
- MSL Handling: Ensure proper storage and baking if the packaging has been opened, due to MSL 3 classification.
❓ FAQ
Q: What is the maximum current I can drive the XL-3433UYC-02 with continuously? A: The Absolute Maximum Rating for continuous forward current is 60mA. While pulses up to 120mA are allowed, exceeding 60mA DC risks thermal degradation.
Q: What does the "MSL Level 3" rating mean for my assembly process? A: It means the component is sensitive to moisture. If the sealed bag is open, you must bake the LEDs before soldering to prevent internal damage (popcorning) during reflow.
Q: Can this LED be used for outdoor automotive applications? A: Yes, the datasheet explicitly lists "Car tail lights" and supports an operating temperature range of -40°C to +85°C, making it suitable for harsh environments.
Q: What is the dominant wavelength range for this Yellow LED? A: The dominant wavelength (λd) ranges from 585nm to 595nm. For precise color matching, you can select specific bins (HY03 to HY06) when ordering.
Q: Is this component ROHS compliant? A: Yes, the datasheet confirms that the environmental protection process complies with the ROHS Directive.
Q: What is the recommended soldering profile for this LED? A: For lead-free processes, peak temperature should not exceed 255°C (with 5-10s soak time above 217°C). For lead processes, the limit is 235°C.
