📌 Product Overview
The XL-504SURC is a standard 5mm (F5) red LED with extended leads, offering a balance of brightness and reliability for general electronic applications. Designed with a water-clear epoxy colloid, it provides consistent luminous output for indicators and status displays. Its long lead configuration simplifies manual and wave soldering processes, making it suitable for both prototype and mass production across various consumer and industrial sectors.
🔧 Typical Applications
- Home appliances and digital devices
- Automotive electronics (indicators, dashboards)
- Lighting decoration and urban signage
- Electronic toys, clocks, and educational equipment
- Medical beauty instruments and traffic control systems
⚙️ Key Technical Specifications
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Luminous Intensity | Iv | 2100 | 3000 | 4000 | mcd | IF=20mA |
| Dominant Wavelength | λd | 615 | 620 | 625 | nm | IF=20mA |
| Forward Voltage | VF | 1.8 | 2.2 | 2.4 | V | IF=20mA |
| Viewing Angle | 2Ø1/2 | - | 30 | - | deg | IF=20mA |
| Spectral Width | Δλ | - | 20 | - | nm | IF=20mA |
⚠️ Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Rating | Unit |
|---|---|---|---|
| Consumed Power | Pd | 70 | mW |
| Max Continuous Forward Current | IF | 20 | mA |
| Peak Forward Current | IFp | 80 | mA |
| Operating Ambient Temperature | Topr | -20 to +85 | °C |
| Storage Temperature | Tstg | -40 to +85 | °C |
| Reflow Soldering | Tsol | 240°C, ≤6s | - |
| Manual Soldering | Tsol | 300°C, 3s | - |
📦 Package, Dimensions & Assembly Notes
The XL-504SURC comes in standard EIA moisture-proof and anti-static packaging. Its dimensions are 5.5mm (dia.) x 5.0mm (height) with 28mm long leads. Soldering must be performed at least 2.0mm from the bottom of the epoxy body to prevent damage. The device is RoHS compliant and has a Moisture Sensitivity Level (MSL) of 2, ensuring straightforward handling and assembly in most production environments.
📈 Sourcing & Supply Considerations
- Standard product with readily available samples for evaluation.
- Consistent supply chain supported by EIA standard packaging.
- Brightness (B3-B6) and voltage (N12-7 to N12-9) binning available for specific application requirements.
- Authenticity can be verified through authorized XINGLIGHT distributors.
❓ FAQ
Q: What is the typical brightness of the XL-504SURC?
A: The typical luminous intensity is 3000 mcd at IF=20mA, with options graded from B3 (2100-2500 mcd) to B6 (3500-4000 mcd).
Q: Is this LED suitable for automotive applications?
A: While designed for automotive electronics, its operating temperature range (-20°C to +85°C) is suitable for non-critical automotive uses. High-reliability applications require further validation.
Q: What is the recommended soldering process?
A: Reflow soldering should be at 240°C for ≤6s, and manual soldering at 300°C for 3s. Maintain a 2.0mm distance from the epoxy body to avoid heat damage.
Q: How is the LED packaged for shipment?
A: Units are packed in moisture-proof, anti-static foil bags to prevent degradation during storage and transit.
Q: Does this LED comply with environmental standards?
A: Yes, the XL-504SURC is RoHS compliant, ensuring it meets environmental protection requirements.
