📌 Product Overview
The XL-504SYGC is a standard 5mm (F5) diameter through-hole LED, designed to provide a reliable and efficient green light source. Characterized by its white epoxy colloid and long leads, this component is engineered for general-purpose use in a wide array of electronic products. Its core design focus is on achieving a balance between high luminous intensity, low power consumption, and long-term operational stability, making it a suitable choice for cost-sensitive and performance-driven applications.
💡 Typical Applications
- Home appliances and digital devices
- Automotive electronics and traffic indicators
- Lighting decoration and urban lighting projects
- Electronic toys, clocks, and teaching equipment
- Medical beauty instruments
📊 Key Technical Specifications
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Luminous Intensity | Iv | 300 | 500 | 700 | mcd | IF=20mA |
| Dominant Wavelength | λd | 565 | / | 575 | nm | IF=20mA |
| Peak Wavelength | λp | / | 570 | / | nm | IF=20mA |
| Forward Voltage | VF | 2.0 | 2.2 | 2.6 | V | IF=20mA |
| Viewing Angle | 2Ø1/2 | / | 30 | / | deg | IF=20mA |
⚡ Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Rating | Unit |
|---|---|---|---|
| Max Continuous Forward Current | IF | 20 | mA |
| Peak Forward Current | IFp | 80 | mA |
| Operating Ambient Temperature | Topr | -20 ~ +85 | °C |
| Storage Ambient Temperature | Tstg | -40 ~ +85 | °C |
| Reflow Soldering | Tsol | 240°C, ≤6s | |
| Manual Soldering | Tsol | 300°C, 3s |
📦 Package, Dimensions & Assembly Notes
The XL-504SYGC is packaged in standard EIA moisture-proof, anti-static foil bags, suitable for automated SMT placement processes. The device features a standard F5 package with dimensions of 5.55.08.7*28mm. For reliable assembly, soldering points must be kept at least 2.0mm away from the bottom of the epoxy colloid to prevent damage. The component has a Moisture Sensitivity Level (MSL) of 2, requiring standard handling procedures.
🔍 Sourcing & Supply Considerations
- Binning options are available for brightness (A4-A6) and voltage (N12-8 to N13-1) to meet specific design requirements.
- Compliance with ROHS standards is guaranteed, ensuring suitability for global markets.
- For large volume orders and lead time confirmation, please contact XINGLIGHT sales or authorized distributors.
- Authenticity can be verified through the original packaging and traceable lot codes.
❓ FAQ
Q: What are the available brightness bins for the XL-504SYGC?
A: The XL-504SYGC offers three standard brightness grades: A4 (300-400 mcd), A5 (400-500 mcd), and A6 (500-700 mcd), all tested at IF=20mA.
Q: Is this LED suitable for reflow soldering in an SMT process?
A: Yes, the XL-504SYGC can withstand reflow soldering at a peak temperature of 240°C for a duration of 6 seconds or less, provided the solder joint is 2.0mm from the colloid.
Q: What is the reliability data for this component?
A: The XL-504SYGC has passed rigorous reliability tests, including a 1000-hour operating life test, high-temperature/high-humidity storage, and thermal cycling, with zero failures recorded in sample testing.
Q: Can the wavelength be specified for a specific application?
A: Yes, wavelength binning is available in four grades (HYG03-HYG06) ranging from 565nm to 575nm to allow for precise color matching in your application.
