ð Product Overview
The XL-DZ504SURD is a standard red through-hole LED manufactured by XINGLIGHT, designed primarily for status indication and general-purpose illumination. ðĄ It features a 6.2x6.2x14mm package with a water-clear red colloid and utilizes a dominant wavelength range of 615nm to 635nm. ð This component is engineered for applications requiring high energy efficiency and long operational life, capable of withstanding operating temperatures ranging from -40â to +85â. Its robust design supports IoT infrastructure, medical devices, and storage server indicators.
ðŊ Typical Applications
This component is suited for environments requiring reliable visual feedback and low power consumption.
- IoT & Networking: Status indicators on storage servers and communication equipment.
- Medical Devices: Signal indicators where ROHS compliance and component reliability are critical.
- Consumer Electronics: Power or function indicators in converters and home appliances.
- Industrial Testing: Visual feedback modules for electronic testing instruments.
ð Key Technical Specifications
The following table outlines the electro-optical characteristics under standard test conditions (Ta=25â, IF=20mA).
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Test Conditions |
|---|---|---|---|---|---|---|
| Luminous Intensity | Iv | 300 | - | 900 | mcd | IF = 20mA |
| Dominant Wavelength | Îŧd | 615 | - | 635 | nm | IF = 20mA |
| Peak Wavelength | Îŧp | - | 625 | - | nm | IF = 20mA |
| Forward Voltage | VF | 1.8 | - | 2.4 | V | IF = 20mA |
| Viewing Angle | 2Ã1/2 | - | 45° | - | deg | IF = 20mA |
| Reverse Current | IR | - | - | âĪ 5 | ΞA | VR = 5V |
ðĄ Note: Specific binning codes (A4-A7 for brightness, HR01-HR04 for wavelength) allow for tight consistency in mass production.
â ïļ Absolute Maximum Ratings & Process Limits
Exceeding these parameters may result in permanent device failure. ð Engineers must design circuits to ensure these limits are never surpassed during operation or transient events.
| Parameter | Symbol | Value | Unit |
|---|---|---|---|
| Max Power Dissipation | PD | 50 | mW |
| Max Continuous Forward Current | IF | 20 | mA |
| Peak Forward Current | IFP | 80 | mA |
| Max Reverse Voltage | VR | 5 | V |
| ESD Susceptibility | ESD | 2000 | V |
| Operating Temperature | TOPR | -40 to +85 | â |
| Storage Temperature | TSTR | -40 to +85 | â |
⥠Caution: The soldering temperature must not exceed 260â for longer than 6 seconds.
ðĶ Package, Dimensions & Assembly Notes
The device is packaged in a moisture-proof and anti-electrostatic foil bag (EIA standard), classified at Moisture Sensitivity Level (MSL) 2.
- Dimensions: The outline measures 6.2x6.2x14mm with a tolerance of Âą0.25mm unless noted.
- Assembly: Lead soldering is permitted up to 260â (âĪ6S). ð For storage, humidity must be <70% RH at 30â. Components should be used within three months of opening; otherwise, baking or nitrogen storage is required to prevent moisture ingress.
ð Sourcing & Supply Considerations
To ensure supply chain stability and technical authenticity, the following steps are recommended:
- Verify Binning: Confirm specific brightness (A4-A7) and voltage (N12-7/8/9) codes match your BOM requirements.
- Sample Testing: Request samples for thermal validation under specific housing conditions.
- Authenticity: Source through XINGLIGHT authorized channels to guarantee ROHS compliance and avoid counterfeits.
â FAQ
Q: What is the forward voltage range for the XL-DZ504SURD?
A: The forward voltage (VF) ranges from a minimum of 1.8V to a maximum of 2.4V when measured at a standard forward current of 20mA.
Q: How should I handle the LEDs regarding moisture sensitivity?
A: This component is MSL Level 2. If the original vacuum-sealed bag is open, components must be used within 3 months (30â / 70% RH). For longer storage, use a desiccant cabinet or nitrogen-filled dry box.
Q: What is the maximum current this LED can handle?
A: The continuous forward current is 20mA. However, it can handle a peak pulse current of up to 80mA, making it suitable for pulse-width modulation (PWM) dimming applications.
Q: Are there specific bins available for color and intensity?
A: Yes. Wavelength is binned between 615-635nm (codes HR01-HR04), and luminous intensity is binned from 300 to 900 mcd (codes A4-A7). Verify these codes when placing large orders to ensure visual consistency.
Q: Is this component suitable for medical devices?
A: Yes, the datasheet explicitly lists "medical treatment" as a typical application. It meets ROHS requirements for environmental safety.
