📌 Product Overview
The XL-304UGC from XINGLIGHT is a 5mm through-hole LED emitting a bright green light. Engineered for high visibility and reliability, it is a standard component for status and indicator applications. Its primary design focus is on providing consistent optical performance in a compact, easy-to-assemble package, making it suitable for a wide range of consumer and industrial products where a dependable visual signal is required.
💡 Typical Applications
- Home Appliances & Digital Devices: Power indicators, status lights.
- Automotive Electronics: Dashboard indicators, control panel feedback.
- Lighting & Decoration: Signs, displays, accent lighting.
- Consumer Electronics: Toys, clocks, remote controls.
- Industrial & Instrumentation: Control panels, medical devices, teaching equipment.
🔍 Key Technical Specifications
| Parameter | Symbol | Min | Typ | Max | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Luminous Intensity | Iv | 8000 | 10000 | 12000 | mcd | IF=20mA |
| Dominant Wavelength | λd | 515 | / | 530 | nm | IF=20mA |
| Peak Wavelength | λp | / | 525 | / | nm | IF=20mA |
| Forward Voltage | VF | 2.8 | 3.0 | 3.4 | V | IF=20mA |
| Viewing Angle | 2Ø1/2 | / | 30 | / | deg | IF=20mA |
⚠️ Absolute Maximum Ratings & Process Limits
Electrical and thermal parameters that must not be exceeded to ensure device integrity. These ratings define the operational boundaries for design and manufacturing. Exceeding these values can cause permanent damage to the LED.
| Parameter | Symbol | Rating | Unit |
|---|---|---|---|
| Consumed Power | Pd | 70 | mW |
| Max Continuous Forward Current | IF | 20 | mA |
| Peak Forward Current | IFp | 80 | mA |
| Operating Ambient Temperature | Topr | -20 ~ +85 | °C |
| Reflow Soldering | Tsol | 240°C, ≤6s | - |
📦 Package, Dimensions & Assembly Notes
The XL-304UGC is packaged in a standard 5mm (T-1 3/4) round package with long leads for through-hole mounting. It is supplied in moisture-proof, anti-static EIA standard packaging. Assembly requires attention to soldering conditions: manual soldering should be performed at 300°C for a maximum of 3s, with the solder joint kept at least 2.0mm from the LED's epoxy body to prevent thermal damage.
🚀 Sourcing & Supply Considerations
- Grading: Available in brightness (C1, C2) and voltage (N13-3, N13-4, N13-5) grades to meet specific BOM requirements.
- Reliability: RoHS compliant and MSL 2 rated, suitable for standard SMT processes with proper handling.
- Supply: For samples, lead times, or volume quotations, please contact our sales team to ensure authentic supply chain channels.
❓ FAQ
Q: What is the typical luminous intensity of the XL-304UGC? A: The typical luminous intensity is 10,000 mcd at IF=20mA. It is available in brightness grades C1 (8,000-10,000 mcd) and C2 (10,000-12,000 mcd).
Q: What are the soldering conditions for this LED? A: For reflow soldering, the temperature must not exceed 240°C for ≤6s. For manual soldering, the temperature must not exceed 300°C for 3s. The solder joint must be at least 2.0mm from the bottom of the epoxy body.
Q: Is the XL-304UGC suitable for automotive applications? A: While the LED is used in automotive electronics, its absolute maximum operating temperature is -20°C to +85°C. For automotive-grade applications requiring higher temperature ranges or specific AEC-Q qualifications, please consult our sales team for alternative components.
Q: What is the Moisture Sensitivity Level (MSL)? A: The XL-304UGC has an MSL rating of 2. This means it is sensitive to moisture and should be baked and used according to standard IPC/JEDEC guidelines if exposed to factory ambient conditions for an extended period.
Q: Does this LED come in different wavelength bins? A: Yes, the dominant wavelength is graded. Standard bins include HG02 (515-520nm), HG03 (520-525nm), and HG04 (525-530nm). Please specify your requirement when ordering.
