📌 Product Overview
The XL-304UWC is a through-hole white LED with a F3/3.8x3.0x5.2x28mm package, offering high luminous intensity (up to 10,000 mcd) and a 10,000K color temperature. Designed for reliability, it operates from -20°C to +85°C and meets ROHS standards. Its low forward voltage (2.8–3.4V) and fast startup make it ideal for compact, energy-efficient designs in consumer and industrial applications.
🔍 Typical Applications
- Home appliances & digital devices
- Automotive electronics
- Lighting decoration & urban lighting
- Medical beauty instruments
- Electronic toys & teaching equipment
⚙️ Key Technical Specifications
| Parameter | Symbol | Min | Typ | Max | Unit | Test Condition |
|---|---|---|---|---|---|---|
| Luminous Intensity | Iv | 6,000 | 8,000 | 10,000 | mcd | IF=20mA |
| Color Temperature | TC | - | 10,000 | - | K | IF=20mA |
| Forward Voltage | VF | 2.8 | 3.0 | 3.4 | V | IF=20mA |
| Viewing Angle | 2Ø1/2 | - | 30 | - | deg | IF=20mA |
🔒 Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Rating | Unit |
|---|---|---|---|
| Power Dissipation | Pd | 70 | mW |
| Max Continuous Forward Current | IF | 20 | mA |
| Peak Forward Current | IFp | 80 | mA |
| Operating Temperature | Topr | -20 ~ +85 | °C |
| Reflow Soldering | Tsol | 240°C ≤6s | - |
📦 Package, Dimensions & Assembly Notes
The XL-304UWC features a moisture-proof, anti-static foil bag package. Key dimensions: 3.8x3.0x5.2mm (body) with 28mm leads. Soldering requires manual welding at 300°C (3s) or reflow at 240°C (≤6s), with a 2.0mm minimum distance from the lead to the epoxy body.
🚀 Sourcing & Supply Considerations
- Grading options available for luminosity (B9/C1) and voltage (N13-3/4/5).
- RoHS-compliant with MSL-2 moisture sensitivity.
- Recommended storage: ≤30°C, ≤70% RH, in original packaging for ≤3 months.
❓ FAQ
Q: What is the luminosity grading for XL-304UWC?
A: Two bins: B9 (6,000–8,000 mcd) and C1 (8,000–10,000 mcd) at IF=20mA.
Q: What are the soldering conditions?
A: Reflow at 240°C (≤6s) or manual solder at 300°C (3s). Keep lead-to-body distance ≥2.0mm.
Q: Is this LED suitable for automotive use?
A: Yes, but high-reliability applications (e.g., traffic control) require additional validation per datasheet.
Q: How should LEDs be stored long-term?
A: Store at ≤30°C, ≤70% RH. For >3 months, use a desiccant or nitrogen-filled container.
Q: What is the reverse current rating?
A: ≤10 μA at VR=5V.
Q: Does the LED comply with RoHS?
A: Yes, it is an RoHS-compliant environmental product.
```
