📌 Product Overview
The XL-5730UBC-02 is a surface-mount device (SMD) LED from XINGLIGHT, housed in a standard 5730 package (5.7mm x 3.0mm). 💡 It utilizes a transparent colloid optimized for high-brightness blue light emission with a peak wavelength of 465nm. This component is specifically engineered to withstand standard infrared reflow soldering processes, making it suitable for high-volume automated manufacturing environments. It is designed primarily for applications requiring compact, high-intensity light sources with consistent color properties.
🚀 Typical Applications
- Commercial Lighting & Display: Ideal for downlights and commercial display units requiring high-intensity blue illumination.
- Backlighting: Suitable for LCD backlight assemblies where uniform color distribution is critical.
- Flexible Light Strips: Designed for decoration lighting and flexible strips that require compact, robust SMD components.
- Signage: Effective for advertising words and light boxes needing clear, vibrant blue light output.
- Fluorescent Replacements: Used in modern LED tubes and light bars to replace traditional fluorescent lighting.
📊 Key Technical Specifications
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Test Conditions |
|---|---|---|---|---|---|---|
| Luminous Intensity | $\Phi$ | 3 | 5 | 8 | LM | $I_F=60mA$ |
| Dominant Wavelength | $\lambda_d$ | 455 | — | 470 | nm | $I_F=60mA$ |
| Peak Wavelength | $\lambda_p$ | — | 465 | — | nm | $I_F=60mA$ |
| Forward Voltage | $V_F$ | 2.8 | — | 3.4 | V | $I_F=60mA$ |
| Viewing Angle | $2\theta_{1/2}$ | — | 120 | — | Deg | $I_F=60mA$ |
👇 Binning Codes: Units are categorized by Brightness (H2-H5) and Voltage (N13-3 to N13-5). Verify specific bin codes during procurement to ensure batch consistency.
🔒 Absolute Maximum Ratings & Process Limits
| Parameter | Symbol | Max. Value | Unit | Notes |
|---|---|---|---|---|
| Max Power Dissipation | $P_D$ | 200 | mW | @ $T_a=25^\circ C$ |
| Max Continuous Forward Current | $I_F$ | 60 | mA | |
| Peak Forward Current | $I_{FP}$ | 120 | mA | Pulse width $\le 0.1ms$ |
| Max Reverse Voltage | $V_R$ | 5 | V | |
| ESD Ability | ESD | 2000 | V | Human Body Model |
| Operating Temperature | $T_{OPR}$ | -40 ~ +85 | $^\circ C$ | |
| Storage Temperature | $T_{STR}$ | -40 ~ +85 | $^\circ C$ |
⚠️ Thermal Warning: Do not exceed the maximum junction temperature. Proper PCB heatsinking is required to maintain reliability under maximum drive currents.
📦 Package, Dimensions & Assembly Notes
- Dimensions: The component features a standard 5730 footprint with Outline Dimensions (L/W/H) of 5.7 × 3.0 × 0.8 mm.
- Packaging: Compliant with EIA standard packaging tape specifications for automated pick-and-place machines.
- MSL: Moisture Sensitivity Level is MSL 3. Ensure proper baking before reflow if the moisture barrier bag has been opened.
- Soldering:
- Lead-Free Process: Peak temp $255^\circ C$ ($+0/-5^\circ C$) for 5-10 seconds above $217^\circ C$.
- Lead Process: Peak temp $235^\circ C$ ($+5/-0^\circ C$) for 10-15 seconds above $183^\circ C$.
🤝 Sourcing & Supply Considerations
- Supply Chain Verification: Verify packaging labels for correct Brightness (H2-H5) and Voltage (N13-3 to N13-5) bin codes upon receipt to match design specifications.
- Authenticity: Source only through authorized XINGLIGHT channels to avoid counterfeit components that may fail reliability tests (e.g., Cold/Hot cycle shock).
- Production Readiness: The product is rated for industrial temperatures ($-40^\circ C$ to $+85^\circ C$); confirm the environmental conditions match your end-application requirements.
❓ Frequently Asked Questions
Q: What is the typical forward voltage for this LED?
A: The typical forward voltage is approximately 3.1V, with a binning range of 2.8V to 3.4V at a drive current of 60mA. Designers should account for the maximum voltage when calculating driver headroom.
Q: Can this LED be used for outdoor lighting applications?
A: The XL-5730UBC-02 has an operating temperature range of -40°C to +85°C, which suits many indoor and commercial environments. For outdoor use, ensure the IP-rated housing provides adequate protection against moisture ingress, as the component itself is not waterproof.
Q: What are the binning codes for color and brightness?
A: Wavelength is binned by codes HB02 to HB05 (450-470nm). Brightness is binned H2 to H5 (3-8 Lumens). Always specify these codes when placing orders to maintain color consistency in your product.
Q: Is this component compatible with lead-free soldering processes?
A: Yes, the datasheet specifies a dedicated profile for lead-free processes allowing a peak temperature of 255°C for short durations, compatible with standard SAC305 solder pastes.
Q: What is the MSL rating for the XL-5730UBC-02?
A: The Moisture Sensitivity Level is 3. Components must be mounted within 168 hours of opening the bag if the floor life is standard, or baked according to IPC/JEDEC standards if exposed longer.
Q: What is the ESD tolerance?
A: The component features an antistatic ability (ESD) of 2000V, requiring standard ESD precautions (wrist straps, ionizers) during manual handling and assembly.
