📌 Product Overview
The XINGLIGHT XL-DZ304UWC is a high-intensity surface-mount device (SMD) designed to serve as a critical visual interface in electronic systems. 💡 This component is specifically engineered for applications requiring reliable status indication and long-term stability, such as storage servers, medical instrumentation, and IoT converters.
Design focus is centered on optical consistency and thermal endurance. With a typical luminous intensity of 8000 mcd and a compact footprint, it provides a balance of visibility and board space efficiency. The product utilizes a water-clear colloid to maximize light output while adhering to ROHS environmental standards.
🚀 Typical Applications
This model is optimized for integration into systems where status feedback is essential. Its robust operating temperature range suits industrial environments.
- Industrial IoT & Networking: Status indicators on converters and communication modules.
- Data Infrastructure: Signal lights for storage servers and rack-mounted equipment.
- Medical Devices: Operation indicators for electronic testing instruments and patient monitoring systems.
- Consumer Electronics: Power or function indicators within enclosed housings.
📊 Key Technical Specifications
The following parameters represent typical performance values at Ta=25℃ to aid in circuit design and binning selection.
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Condition |
|---|---|---|---|---|---|---|
| Luminous Intensity | Iv | - | 8000 | - | mcd | IF=20mA |
| Color Temperature | TC | 6000 | - | 8000 | K | IF=20mA |
| Forward Voltage | Vf | 2.8 | - | 3.6 | V | IF=20mA |
| Viewing Angle | 2Ø1/2 | - | 45° | - | Deg | IF=20mA |
| Rendering Index | Ra | - | 72 | - | - | IF=20mA |
| Reverse Current | Ir | - | - | ≤1 | μA | VR=5V |
Note: Specific brightness bins (B9, C1) and voltage bins (N13-3 to N13-6) allow for tighter supply chain control.
⚠️ Absolute Maximum Ratings & Process Limits
Exceeding these ratings may cause permanent device failure. 👇 These limits are critical for establishing safety margins in power supply design and thermal management.
| Parameter | Symbol | Value | Unit |
|---|---|---|---|
| Max Power Dissipation | Pd | 75 | mW |
| Max Continuous Forward Current | If | 20 | mA |
| Peak Forward Current | Ifp | 80 | mA |
| Max Reverse Voltage | Vr | 5 | V |
| ESD Tolerance | ESD | 2000 | V |
| Operating Temperature | Topr | -40 ~ +85 | ℃ |
| Storage Temperature | Tstr | -40 ~ +85 | ℃ |
| Soldering Temp/Time | Tsol | 260 ≤ 6S | ℃/S |
🔒 Package, Dimensions & Assembly Notes
The XL-DZ304UWC features a compact rectangular form factor.
- Dimensions: 7.5mm (L) x 6.5mm (W) x 4.5mm (H).
- Tolerance: ±0.25mm (unless noted).
- Packaging: EIA standard compliant, shipped in moisture-proof and anti-electrostatic foil bags (MSL Level 2).
- Assembly: Suitable for standard reflow soldering processes. 🔒 Ensure the storage environment does not exceed 30℃ or 70% RH to prevent moisture absorption prior to mounting.
📈 Sourcing & Supply Considerations
To ensure production yield and consistency, procurement teams should verify bin codes for brightness and voltage.
- Binning Strategy: Specify voltage codes (e.g., N13-4) and brightness codes (e.g., C1) to maintain uniformity across batches.
- Authenticity: Source through authorized channels to guarantee ROHS compliance and avoid counterfeits.
- Storage: Adhere to MSL Level 2 handling; if the floor life exceeds 3 months, baking is required.
❓ FAQ
Q: What is the expected forward voltage range for this LED?
A: The forward voltage (Vf) ranges from a minimum of 2.8V to a maximum of 3.6V at 20mA. For precise power regulation, specific bins (N13-3 through N13-6) are available in 0.2V increments.
Q: Is the XL-DZ304UWC suitable for high-temperature environments?
A: Yes, the component is rated for an operating temperature range of -40℃ to +85℃, making it suitable for industrial servers and communication equipment subjected to thermal stress.
Q: How should I handle the component regarding moisture sensitivity?
A: This LED is classified as MSL Level 2. It can be exposed to a floor life of up to 1 year at <30℃/60% RH. If the moisture barrier bag is breached and not used within 3 months, baking or dry storage is necessary.
Q: What is the maximum current I can drive through this LED?
A: The maximum continuous forward current is 20mA. However, it can withstand a peak pulse current of up to 80mA, allowing for brief multiplexing or pulsing applications.
Q: What packaging options are available for mass production assembly?
A: The product comes in EIA standard packaging, specifically moisture-proof and anti-electrostatic foil bags (In Bags), ensuring protection during transit and storage prior to SMT placement.
