The XINGLIGHT XL-DZT502SYGD1 is a standard F5 through-hole LED featuring a dominant wavelength of 565–575 nm and a green epoxy colloid. Designed for low-voltage DC drive (20 mA), this component suits general indication, automotive electronics, and consumer appliances. This analysis outlines critical optical and electrical limits for engineers evaluating design compatibility and BOM risk.
📌 Product Overview
The XL-DZT502SYGD1 is a standard 5mm diameter (F5) radial LED manufactured by XINGLIGHT. It is designed to emit a standard green light (Yellow-Green chip within Green colloid) with a dominant wavelength range of 565–575 nm. 💡 This component features a 35-degree viewing angle and is built for long operating life with high energy efficiency.
👇 Target applications include general status indicators, dashboard illumination in automotive electronics, and backlighting for consumer appliances. The device utilizes a low-voltage DC drive and is constructed to meet RoHS environmental standards, making it suitable for modern lead-free assembly processes.
💡 Typical Applications
Based on the provided datasheet characteristics, the XL-DZT502SYGD1 is engineered for the following functional uses:
- Indication & Feedback: Status lights in home appliances (HVAC, kitchen equipment) and digital communication devices.
- Automotive Electronics: 🚗 Non-critical internal dashboard illumination and control panel indicators (operating temperature rated up to 85°C).
- Consumer Electronics: Electronic clocks, toys, and educational equipment requiring clear visual indication.
- Lighting & Decoration: 💡 Urban lighting accents and decorative lamp fixtures where specific wavelength consistency is required.
- Instrumentation: Basic signal indicators for medical or industrial beauty instruments.
⚡ Key Technical Specifications
The following electro-optical parameters are measured under standard test conditions (Ta=25°C, IF=20mA).
| Parameter | Symbol | Min. | Typ. | Max. | Unit | Condition |
|---|---|---|---|---|---|---|
| Luminous Intensity | Iv | 50 | - | 300 | mcd | IF = 20mA |
| Dominant Wavelength | λd | 560 | - | 575 | nm | IF = 20mA |
| Peak Wavelength | λp | - | 570 | - | nm | IF = 20mA |
| Forward Voltage | VF | 1.8 | - | 2.4 | V | IF = 20mA |
| Viewing Angle | 2Ø1/2 | - | 35 | - | deg | IF = 20mA |
| Spectral Width | △λ | - | 30 | - | nm | IF = 20mA |
| Reverse Current | IR | - | - | ≤5 | μA | VR = 5V |
⚠️ Binning Note: The datasheet indicates specific binning codes for intensity (A1-A3), voltage (N12-7 to N12-9), and wavelength (HYG01-HYG06). 📈 Engineers should verify specific bin requirements with the supply chain prior to mass production to ensure color consistency.
🔒 Absolute Maximum Ratings & Process Limits
Exceeding these ratings may cause permanent damage to the device. Strict adherence is required for reliability assurance.
| Parameter | Symbol | Rating | Unit | Notes |
|---|---|---|---|---|
| Power Dissipation | Pd | 50 | mW | - |
| Max Continuous Forward Current | IF | 20 | mA | Derate above 25°C ambient |
| Peak Forward Current | IFp | 80 | mA | Pulse duration dependent |
| Operating Temperature | Topr | -40 ~ +85 | °C | Ambient range |
| Storage Temperature | Tstg | -40 ~ +85 | °C | - |
| Reverse Voltage | VR | 5 | V | Maximum allowable |
| Soldering (Wave) | Tsol | 240 | °C | Max 6 seconds |
| Soldering (Manual) | Tsol | 300 | °C | Max 3 seconds |
⚠️ Critical Process Warning: The soldering point must be located at least 2.0mm from the bottom of the epoxy colloid to prevent thermal damage during assembly.
📦 Package, Dimensions & Assembly Notes
The XL-DZT502SYGD1 utilizes a standard F5 radial lead formation with a metal seat/holder, suitable for wave soldering or manual insertion processes.
- Dimensions: 11.3mm (Total Length) x 15.0mm (Height/Lead Span) x 10.3mm (Width).
- Tolerance: ±0.25mm unless otherwise noted.
- Moisture Sensitivity Level (MSL): Level 2. Components must be soldered within 1 year of the bag seal date, or baked according to IPC/JEDEC standards if the floor life is exceeded.
- Packaging: Supplied in moisture-proof and anti-static foil bags (EIA standard).
- Lead Integrity: 🛠️ Verified to withstand 3 cycles of 90-degree bending under a 2.5N load.
🚀 Sourcing & Supply Considerations
When integrating the XL-DZT502SYGD1 into BOMs, procurement teams should consider the following logistics:
- Supply Chain Verification: Ensure distributors are sourcing XINGLIGHT products to manage MSL 2 moisture sensitivity correctly.
- Binning Availability: 📦 Verify current stock availability for specific wavelength bins (HYG codes) and voltage bins to avoid visual inconsistencies in the final product.
- Lead Time: As a standard LED component, lead times are generally stable, but RoHS compliance and environmental testing data should be requested for high-reliability applications.
- Sample Evaluation: 🔍 Request pre-production samples to validate the luminous intensity (Iv) spread across the A1-A3 bins for your specific light pipe design.
❓ FAQ
Q: What is the forward voltage requirement for the XL-DZT502SYGD1?
A: The typical forward voltage ranges from 1.8V to 2.4V at a rated forward current of 20mA. Designers should select resistor values based on the maximum forward voltage (2.4V) to ensure consistent current regulation across the supply voltage tolerance.
Q: What is the viewing angle of this LED?
A: The datasheet specifies a typical viewing angle (2Ø1/2) of 35 degrees. This makes it suitable for focused indicator lights rather than wide-area diffuse illumination.
Q: What are the soldering temperature limits for this component?
A: For wave soldering, the limit is 240°C for ≤6 seconds. For manual welding, the limit is 300°C for ≤3 seconds. Crucially, the solder joint must be at least 2.0mm away from the epoxy body to prevent thermal stress damage.
Q: Does this LED support high-temperature environments?
A: Yes, the operating ambient temperature range is -40°C to +85°C, allowing it to function in harsh environments such as automotive interiors or industrial control panels.
Q: Is the XL-DZT502SYGD1 RoHS compliant?
A: Yes, the datasheet explicitly lists the product as an environmental protection product meeting ROHS requirements, ensuring it is free from hazardous substances as per standard regulations.
