📌 Product Overview
The XL-5730UWC-05 from XINGLIGHT is a surface-mount device (SMD) LED housed in a standard 5730 package (5.7mm x 3.0mm x 0.8mm). 💡 It is engineered to provide high-brightness white illumination with a power dissipation of 500mW, making it suitable for compact lighting arrays and general-purpose fixtures.
Typified by a forward voltage range of 2.8V to 3.4V, this component balances efficiency with thermal performance. 👇 It utilizes a yellow colloid to enhance light extraction and is fully compliant with RoHS directives, ensuring suitability for environmentally conscious designs in consumer and commercial electronics.
🚀 Typical Applications
Based on its luminous intensity (45-70 lm) and 120-degree viewing angle, the XL-5730UWC-05 is optimized for uniform light distribution in the following scenarios:
- Commercial Lighting: Downlights and office ceiling panels.
- Linear Lighting: Fluorescent tube replacements (T5/T8) and rigid light strips.
- Signage: Illuminated advertising characters and light boxes requiring consistent color temperature.
- Backlighting: LCD display units and indicator panels.
- Decorative Lighting: Flexible strip lighting for ambient effects.
📊 Key Technical Specifications
The following optical and electrical parameters are measured at a test condition of IF = 150mA (Ta=25°C).
| Parameter | Symbol | Min. | Typ. | Max. | Unit |
|---|---|---|---|---|---|
| Luminous Intensity | Φ | 45 | - | 70 | LM |
| Color Temperature | TC | 6000 | - | 7500 | K |
| Forward Voltage | VF | 2.8 | - | 3.4 | V |
| Viewing Angle | 2θ1/2 | - | - | 120 | Deg |
| Color Rendering Index | Ra | - | 70 | - | - |
| Reverse Current | IR | - | - | 5 | μA |
⚠️ Absolute Maximum Ratings & Process Limits
Exceeding these values may result in permanent device failure. These ratings apply under Ta=25°C unless otherwise specified.
| Parameter | Symbol | Max. Value | Unit | Notes |
|---|---|---|---|---|
| Max Power Dissipation | PD | 500 | mW | Derate above ambient temp |
| Max Continuous Forward Current | IF | 150 | mA | - |
| Peak Forward Current | IFP | 300 | mA | Pulse width ≤0.1ms, Duty ≤1/10 |
| Max Reverse Voltage | VR | 5 | V | - |
| ESD Capability | ESD | 2000 | V | Human Body Model (HBM) |
| Operating Temperature | TOPR | -40 ~ +85 | °C | - |
| Storage Temperature | TSTR | -40 ~ +85 | °C | - |
| Soldering Temp/Time | TSOL | 260 | °C | ≤6 Seconds |
📦 Package, Dimensions & Assembly Notes
- Dimensions: The physical outline is 5.7mm (L) x 3.0mm (W) x 0.8mm (H).
- Moisture Sensitivity: The component is classified as MSL 3. It must be baked prior to reflow if the floor life has been exceeded to prevent pop-corning damage.
- Soldering Compatibility: Designed for infrared reflow soldering processes. Lead-free profiles peak at 255°C (max), while leaded profiles peak at 235°C.
- Packaging: Supplied in EIA standard compliant packaging for seamless integration into automated SMT pick-and-place machines.
🛒 Sourcing & Supply Considerations
- Binning Codes: Verify specific Bin codes (Brightness J6-J8, Voltage N13-3 to N13-5, CCT UW9-13) to ensure lot-to-lot consistency in color and brightness.
- Cross-Reference: While compatible with standard 5730 footprints, verify thermal pad dimensions if swapping from other manufacturers.
- Procurement: Confirm supply chain authenticity to avoid non-compliant or counterfeit components that may not meet the ROHS or reliability specs.
❓ FAQ
Q: What is the forward current requirement for this LED?
A: The typical design current is 150mA. However, the absolute maximum continuous forward current is 150mA; pulsed operation can go up to 300mA provided the duty cycle does not exceed 10%.
Q: What are the storage requirements to prevent moisture damage?
A: The XL-5730UWC-05 has a Moisture Sensitivity Level (MSL) of 3. If the moisture barrier bag has been open for more than 168 hours, baking is required before reflow soldering to prevent internal cracking.
Q: Can this component be used for outdoor applications?
A: While the operating temperature range is -40°C to +85°C, the LED is primarily designed for indoor commercial lighting (tubes, downlights). For outdoor use, additional waterproofing (IP rating) and thermal management must be integrated into the fixture design.
Q: What is the viewing angle of this 5730 LED?
A: The typical viewing angle (2θ1/2) is 120 degrees. This wide angle makes it suitable for area lighting and backlighting where uniform light diffusion is preferred over a focused spotlight.
Q: How should I handle the component during SMT assembly?
A: Use standard EIA standard packaging for pick-and-place. Ensure the reflow profile adheres to the specified limits: max 260°C for leaded (≤6s) or 255°C for lead-free processes. Avoid exceeding the peak temperature to prevent degradation of the yellow colloid.
