📌 Product Overview
The XL-B324SURUBC is a high-brightness red/blue dual-color LED with a transparent epoxy colloid, housed in a compact F3 (3.8x3.0x5.2mm) package. Designed for versatility, it targets applications requiring dual-color output, such as signal indication and backlighting. The device operates on low-voltage DC drive, offering fast startup and long operating life to reduce maintenance costs in mass-produced assemblies.
🔍 Typical Applications
- Backlight modules for displays
- Automotive interior lighting and indicators
- Signal indication devices
- Smart home control panels
- General-purpose lighting
⚙️ Key Technical Specifications
| Parameter | Red (Min/Typ/Max) | Blue (Min/Typ/Max) | Unit |
|---|---|---|---|
| Luminous Intensity | 400 / / 700 | 1200 / / 2100 | mcd |
| Dominant Wavelength | 630 / / 640 | 460 / / 470 | nm |
| Forward Voltage | 1.8 / / 2.4 | 2.8 / / 3.4 | V |
| Viewing Angle | / 30 / | / 30 / | deg |
🔒 Absolute Maximum Ratings & Process Limits
| Parameter | Red | Blue | Unit |
|---|---|---|---|
| Max Power Dissipation | 50 | 70 | mW |
| Max Continuous Forward Current | 20 | 20 | mA |
| Peak Forward Current | 80 | 80 | mA |
| Operating Temperature | -20 ~ +85 | -20 ~ +85 | °C |
| Reflow Soldering | 240°C ≤ 6s | 240°C ≤ 6s | — |
📦 Package, Dimensions & Assembly Notes
- Package Type: F3 (3.8x3.0x5.2mm) with transparent colloid.
- Soldering: Reflow (240°C, ≤6s) or manual (300°C, 3s). Keep solder joint ≥2.0mm from colloid base.
- MSL: Moisture Sensitivity Level 2. Requires EIA standard packaging.
🚀 Sourcing & Supply Considerations
- Verify brightness/voltage/wavelength binning codes (e.g., A6, N12-9) for consistency.
- Ensure ROHS compliance and MSL-2 handling for manufacturing reliability.
- Request samples for validation before mass production to mitigate cross-referencing risks.
❓ FAQ
Q: What are the brightness binning options for this LED?
A: Red LEDs are graded A5 (400-500 mcd) to A6 (500-700 mcd); blue LEDs range from A9 (1200-1500 mcd) to B2 (1800-2100 mcd).
Q: Is this LED suitable for automotive applications?
A: Yes, it meets automotive interior requirements with a -20°C to +85°C operating range and long-term reliability testing.
Q: What soldering precautions should be followed?
A: Reflow at 240°C (≤6s) or manual solder at 300°C (3s). Maintain a 2.0mm distance from the colloid base to prevent damage.
Q: How does ROHS compliance affect production?
A: As a ROHS-compliant component, it avoids hazardous materials, simplifying regulatory compliance for global markets.
Q: Can this LED replace single-color alternatives in existing designs?
A: Yes, its dual-color capability and compact footprint offer a drop-in solution for applications needing red/blue indication.
